Fireplace and Venting Specifications
for
architects
&
designers
IMPORTANT
This booklet is intended as a basic
specification guide for architects,
designers and builders. Please
refer to the Instruction Manual
supplied with the fireplace for
detailed information regarding
installation and operation.
Product installation manuals can
also be viewed at:
www.townandcountryfireplaces.com
Model TC42 Series C
1
TC42.CE
For reference only. Consult Manual before installation
TC42
Series C
210611-11
Advertisement
Table of Contents
Related Manuals for Town & Country Fireplaces TC42
Summary of Contents for Town & Country Fireplaces TC42
- Page 1 Please refer to the Instruction Manual supplied with the fireplace for detailed information regarding installation and operation. Product installation manuals can also be viewed at: www.townandcountryfireplaces.com Model TC42 Series C For reference only. Consult Manual before installation TC42.CE 210611-11...
-
Page 2: Fireplace Dimensions
Fireplace Dimensions TC42.CE Cad Drawing Available at www.townandcountryfireplaces.com Examples of Common Locations For reference only. Consult Manual before installation TC42.CE 210611-11... -
Page 3: Mantel Clearance Chart
Vertical vent pipe ....1 3/4" (45mm) 4” Horizontal vent pipe ” (Top, sides and bottom) ..1 3/4" (45mm) UNIT MAY BE RECESSED UP TO 6" WITH NON-COMBUSTIBLE MASONRY TYPE MATERIAL For reference only. Consult Manual before installation TC42.CE 210611-11... -
Page 4: Non-Combustible Board Detail
5 1/2" to the sides can be done with of the framing edges. conventional lumber Minimum Combustible Framing Dimensions Including Sheetrock NOTE: Fireplace should be in its final location before framing. For reference only. Consult Manual before installation TC42.CE 210611-11... -
Page 5: Maestro Control System
No building material is permitted to protrude past the framing edges GLASS attached to the fireplace under ANY circumstance. FRAME NON-COMBUSTIBLE FINISH MATERIAL For reference only. Consult Manual before installation TC42.CE 210611-11... - Page 6 18" from the center of the flue outlet to the outside face of the outer wall. The height will need to be increased if a longer horizontal pipe is required. For reference only. Consult Manual before installation TC42.CE 210611-11...
- Page 7 TCVT Wall Vent Cad Drawing horizontal run. For each additional 90° elbow, Available at or an equal combination of elbows, reduce www.townandcountryfireplaces. horizontal vent run by 2 feet. Ensure vent pipe is properly supported. For reference only. Consult Manual before installation TC42.CE 210611-11...
- Page 8 TCVT Roof Vent Cad Drawing horizontal run. For each additional 90° elbow, Available at or an equal combination of elbows, reduce www.townandcountryfireplaces.com horizontal vent run by 2 feet. Ensure vent pipe is properly supported. For reference only. Consult Manual before installation TC42.CE 210611-11...
-
Page 9: Vent Terminal Clearance
** only permitted if veranda, porch, deck, or balcony is fully open on a minimum of 2 sides beneath the floor* * as specified in CGA B149 Installation Codes, Note: local Codes or Regulation may require different clearances * for U.S.A. Installations follow the current National Fuel Gas Code, ANSI #Z21.50.b For reference only. Consult Manual before installation TC42.CE 210611-11... - Page 10 Power Vent Terminals Wall Termination Roof Termination Flush Mount Horizontal Termination Cad Drawings available at www.townandcountryfireplaces.com Direct Vent Terminals Standard Venting Standard Venting Stainless Steel Standard Venting Roof Termination Wall Termination Termination for Condo Installation Cad Drawings available at www.townandcountryfireplaces.com TC42.CE 210611-11...
- Page 11 For personal service pertaining to specific projects, contact: Town & Country Architect Resource Planner architects@pacificenergy.net Web: www.townandcountryfireplaces.com Phone: (250) 748-1184 Toll Free: 1-877-715-2664 2975 Allenby Road, Duncan, BC Canada V9L 6V8 Printed in Canada...
