Town & Country Fireplaces TC42 Installation Instructions Manual

Tc42 heartwood burner
Hide thumbs Also See for TC42:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Operating Instructions, Instruction and Installation Manual
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
These instructions are supplementary to the Installation and
Operating Instructions supplied with the fireplace and should be
kept together. Refer to the Installation and Operating Instructions
for proper gas supply, safety requirements and operating
instructions
290409-12
TC42
HEARTWOOD
BURNER INSTALLATION
INSTRUCTIONS
PART#
TC42.NG05.C
FOR TC42
TC42.NG05.C
5056.426.C5

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TC42 and is the answer not in the manual?

Questions and answers

Related Manuals for Town & Country Fireplaces TC42

Summary of Contents for Town & Country Fireplaces TC42

  • Page 1 These instructions are supplementary to the Installation and Operating Instructions supplied with the fireplace and should be kept together. Refer to the Installation and Operating Instructions for proper gas supply, safety requirements and operating instructions TC42 HEARTWOOD BURNER INSTALLATION INSTRUCTIONS PART# TC42.NG05.C FOR TC42 290409-12 TC42.NG05.C 5056.426.C5...

  • Page 2: Contents Of Package

    Contents of Package • BURNER ASSEMBLY (including pilot and manifold) • LOG GRATE • EMBER MATERIAL (one bag) • COAL CHUNKS (one bag) • VERMICULITE (one bag) • HARDWARE PACKAGE TC42.NG05.C 290409-12...
  • Page 3 4. Attach spark electrode (ORANGE) and Fig. # 4 sensor leads to the electrical bulk head. (Fig. #4) (The spark electrode connection has a red dot above it) Fig. # 5 5. P osition the grate over the burner tray and attach to the floor with two screws through holes located behind the front legs of the grate. (Fig. # 5) TC42.NG05.C 290409-12...

  • Page 4: Ember Material

    Ember material placement and amount will affect flame appearance. More ember material results in lower flame height. Add or remove as needed until desired flame affect. Reduce the amount used on Propane models, as too much will create soot. Fig. # 6 Embers only in this area. Fig. # 6a Embers, coal chunks and lava rock. TC42.NG05.C 290409-12...

  • Page 5: Log Set Assembly

    LEFT FRONT LOG, #3 Fig. #10 Fig. #12 Fig. #11 LOG WITH HOLE, #4 RIGHT CENTER LOG, #5 FRONT RIGHT LOG, #6 Fig. #13 Fig. #15 Fig. #14 RIGHT BASE LOG, #7 CENTER TWIG, #8 CENTER BASE CHUNK, #9 TC42.NG05.C 290409-12...

  • Page 6: Propane Conversion

    (Fig. #18) manufacturer's instructions supplied with the kit. 5. Fully open the primary air shutter. Reinstall the manifold assembly CAUTION The gas supply and electrical power must be shut off before proceeding with the conversion. TC42.NG05.C 290409-12...
  • Page 7 (Fig. #19) Fig. # 20 8. S lide the pilot adjustment band over and ensure that the hole in the orifice band is showing. (Fig. #20 shows NG position, Fig. # 21 shows LP position) Fig. #21 Fig. # 22 Remove the minimum rate screw located in the valve. (Fig. #22) Minimum rate screw TC42.NG05.C 290409-12...
  • Page 8 Peel off the protective backing and apply the conversion label directly over the gas specifications on the rating label. Fig #26 14. A ttach the access panel to the side of the firebox with the previously removed screws. (Fig. #26) Note: Gasket must be installed with access panel. TC42.NG05.C 290409-12...

  • Page 9: Gas Pressure Check

    Correct gas pressure requirement: Supply Pressure Natural Gas Propane (For purpose of input adjustment) Minimum 5.0" WC 12.5" WC Maximum 13.9" WC 13.9" WC Manifold Pressure Maximum 3.8" WC 11.0w" WC Minimum 2.1" WC 5.5" WC TC42.NG05.C 290409-12...

  • Page 10: Burner Flame Adjustment

    Operating Instructions manual. 2. Remove the log set and set aside. 3. Loosen the screw in the Primary Air Shutter. 4. Rotate the shutter to increase or decrease the amount of primary air. 5. Reassemble in reverse order. TC42.NG05.C 290409-12...

  • Page 11: Replacement Parts

    #5..MAIN SUPPLY TUBE (FLEX) ..... 5019.223 #2..9 PCS LOG SET ......... 5098.32 #6..PILOT TUBE (FLEX) ......5019.225 #3..ORIFICE, NATURAL GAS (#25) ..5022.12 #7..PROPANE CONVERSION KIT ... TC42.LPCEO1 NOT SHOWN KIT CONTENTS: #3..ORIFICE, NATURAL GAS (#32) #1..
  • Page 12 TECHNICAL SUPPORT: 1-888-715-2664 www.townandcountryfireplaces.net 2975 Allenby Rd., Duncan, BC V9L 6V8 Printed in Canada...
