M7 Stationary HD Megapixel IP Camera Series
User Manual
3.1.7.2 Scheduled Recording
Recordings can be scheduled per camera and for specific dates and times in either a continuous mode or
an alerts-based mode.
1. Click the 'Schedule REC Setting' radio button and the 'Set Schedule' button to open a "Set
Schedule" window.
2. Select the camera of your choice from the 'Camera Select' drop down menu.
3. Decide if you would M7CMS to record live video on a continuous basis or prefer to only record
video in accordance with predefined alert-based events.
Continuous Recording Mode
1) Click the 'Continuous' radio button.
2) Set the Continuous Recording Schedule by highlighting all DATE/TIME cells (one cell is
equal to one hour).
Alerts Recording Mode
1) Click the radio button(s) next to one of the following recording options:
a. Motion (initiate recording when a motion detection alert is triggered)
b. I/O (initiate recording when an input/output fault event is detected)
c. Motion, I/O (alert is triggered with either event)
2) Click on the cells (or drag the cursor across multiple cells) of the timetable representing
the DATE/TIME of your schedule. One cell is equal to one hour.
The color of the cell indicates the recording methods
© 2001 - 2016 Microseven Systems, LLC
(Light blue) Motion detection trigger
(Pink) I/O alerts detection trigger
(Dark blue) Motion detection trigger + I/O alerts detection trigger
(Yellow) Continuous
