To remove a camera group, perform the following steps:
1. Click the M7CMS 'Add Camera' button to display the Microseven Camera popup menu.
2. Click the 'Add Group' radio button.
3. Click 'OK' to display a Microseven Camera window and Camera Group List tab.
4. From the list, select the camera group you wish to delete.
5. Click 'Delete'.
6. Click 'OK' to save the changes and click 'Close' to close the window.
To add a camera to an existing camera group, perform the following steps:
1. Click the M7CMS 'Add Camera' button to display the Microseven Camera popup menu.
2. Click the 'Add Camera' radio button and select the group of your choice from the pulldown
menu.
3. Click 'OK' to close the dialog box and open the Camera List menu.
4. If necessary, click the 'Search' button to search for cameras. A list of results will be displayed in a
search window. Select a camera from the list of results.
5. In the Search window, highlight the camera from the list and click the 'Select' button to pre-load
the camera information.
6. Click the 'Add' button to add the camera to the camera group.
7. Click 'OK' to save the changes and close the window.
Note: M7CMS allows you to add IP cameras using CamID and PIN information supplied by the Cam
Locator. In situations where the CamID and PIN information is not available, a camera can be added to
the system using the camera's IP address. Port forwarding is required for cameras added to the system
via IP address. If CamID and PIN information is available, port forwarding is not required.
