- Page 1 Product Operation Manual MSH-RD080PTW IR Middle Speed P/T IP Camera Microseven Systems, Inc. Walnut, California 91789, USA...
-
Page 2: Copyright Notice
Copyright © 2002-2008 Microseven Systems, Inc. All Rights Reserved. Microseven Systems, Inc. provides this operation manual “as is” without warranty of any kind, either express or implied, including, but not limited to the implied warranties of merchantability and fitness for a particular purchase. Microseven Systems, Inc. may make improvements and/or changes in the product(s) and/or the program(s) described in this manual at any time and without notice. - Page 3 Microseven MSH-RD080PTW IR Middle Speed P/T IP Camera ® - 3 - Notes: Please read the following label before connecting or operating the equipment. VER:1.0 The exclamation point within an equilateral triangle is intended to alert the user to the...
-
Page 4: Table Of Contents
Microseven MSH-RD080PTW IR Middle Speed P/T IP Camera ® - 4 - Contents ………………………………………………………………………………… 1. Preface ………………………………………………………………………………… 2. Key Features …………………………………………………………………………………………… 6 3. Notes ……………………………………………………………… 4. Instructions of Main Parts ……………………………………………………………………… 5. Connections 6. Camera Operation Instruction …………………………………………………………..……… 7. Installation ………………………………………………………….……………………….………... -
Page 5: Preface
- 5 - 1. Preface MSH-RD080PTW IR Middle Speed P/T IP Camera adopts SONY CCD, with bright and exquisite images. As video & audio multi-media equipment that based on network transmission, which adopts built-in and multi-media communication technology, the camera is a multi-media network terminal that can directly connect to the network. -
Page 6: Notes
Use the camera under conditions where temperature is between -10° + 50° and humidity is below 95%. H. The power supply for MSH-RD080PTW is DC12V. The adapter with electric current of over 2A is recommended. The pictures in the manual are for reference. -
Page 7: Instructions Of Main Parts
Microseven MSH-RD080PTW IR Middle Speed P/T IP Camera ® - 7 - 4. Instructions for Main Parts ① ② ⑦ ⑥ ⑤ ④ ③ ⑧ ⑨ ⑩ ① Audio out put terminal (yellow) ② Video output terminal ③ Audio input terminal (black) ④... -
Page 8: Connections
Microseven MSH-RD080PTW IR Middle Speed P/T IP Camera ® - 8 - 5. Connections 5.1 Power terminal connections 5.2 Video output terminal connection 5.3 Audio input terminal connection © 2002-2008 Microseven Systems, Inc. All Rights Reserved. - Page 9 Microseven MSH-RD080PTW IR Middle Speed P/T IP Camera ® - 9 - 5.4 Audio output terminal connection 5.5 Audio output terminal connection 4 Alarm Lines - alarm input A - alarm input B - alarm output A - alarm output B 5.6 Network socket terminal connection...
-
Page 10: Camera Operation Instruction
Microseven MSH-RD080PTW IR Middle Speed P/T IP Camera ® - 10 - 5.8 Audio output terminal connection - 8PIN standard GM line - Ultra-five - Recommended maximum length: 80m 6. Camera Operation Instruction 5.1 PTZ operation Users can use control the PTZ by client software to realize “up, down, left, right” movements to track moving targets or mobile video images. - Page 11 Microseven MSH-RD080PTW IR Middle Speed P/T IP Camera ® - 11 - Ask an expert about the bearing capability and structure of the installation surface, if the surface is not solid enough, the camera may drop down. To get the weight of camera please refer to the product specification.
-
Page 12: Basic System Diagram And Operating Circumstance
Microseven MSH-RD080PTW IR Middle Speed P/T IP Camera ® - 12 - 8. Basic System Diagram and Operating Circumstance MSH-RD080PTW Operating environment After the equipment installed and connected to the network, it should be operated on Server Software Platform of Microseven Digital Video Server. - Page 13 Microseven MSH-RD080PTW IR Middle Speed P/T IP Camera ® - 13 - UP, down, left, right and auto pan/tilt Basic Function Max. 20m IR night vision distance IR wavelength 850mm, φ5 x 24 pcs QCIF: 176 * 144 (PAL), 176*120 (NTSC)
