Menu Map

Main Menu Sub Menus

Input Selection

CVBS 1, CVBS 2, S-Video, Component, VGA, 3G-SDI, DVI, HDMI, Test Pattern, Main/DVI, Sub/HDMI, Dual Pipe

Test Pattern

Gray V Bars, Gray H Bars, Aspect Test, Alignment Grid, Warp Adjust, SMPTE, Chequerboard, White Field, Black
Field, Convergence, Custom 1, Custom 2, Custom 3, Custom 4.

Lens

Zoom In (command)
Zoom Stop (command)
Zoom Out (command)
Focus Near (command)
Focus Stop (command)
Focus Far (command)
Center Lens (command)
Nudge
Up (command)
Down (command)
Left (command)
Right (command)
Rev E November 2012
MENU MAP Operating Guide
Notes
Some of the information in this menu
map is summarised. See the actual
menu on the projector for full detail.
The underlined text represents
the factory default value for each
setting.
Op 21
