3.2
Connectors
Power Supply
& Not Used
RS-485
Connections
PSTN line
Serial DTE
3.3
Environmental conditions
Temperature in use
Humidity in use
3.4
Power Supply Specifications
Input voltage range:
Typical power consumption :
Bausch Datacom NV
DinBox PSTN Reference manual – V1.3
4-pin header (MSTBO2.5/4-GR(L)-5.08)
pitch : 5.08 mm / Inom : 12 A / Unom : 250 V
4-pin plug (MVSTBW2.5/4-ST-5.08)
pitch : 5.08 mm / Inom : 12 A / Unom : 250 V / Max. conductor cross section, flexible : 2.5 mm²
4-pin header (MSTBO2.5/4-GR(L)-5.08)
pitch : 5.08 mm / Inom : 12 A / Unom : 250 V
4-pin plug (MVSTBW2.5/4-ST-5.08)
pitch : 5.08 mm / Inom : 12 A / Unom : 250 V / Max. conductor cross section, flexible : 2.5 mm²
RJ-11
A'
A
B
B'
RJ-45 8x8 (Molex)
CTS
RTS
RI
GND
DTR
TXD
RXD
DCD
-10°C / + 50°C
10% - 75% (non condensing)
10 – 40 Vdc regulated
150mA (Max., Operating on-line)
9
RS-485
4
3
2
1
Line
RJ-11
TxD
RxD
WD
DCD
Serial DTE
RJ-45
x
x
-
+
Not
Power
Used
Supply
