- Page 1 © Copyright 2005. Black Box Corporation. All rights reserved. 1000 Park Drive • Lawrence, PA 15055-1018 • 724-746-5500 • Fax 724-746-0746...
- Page 2 Order toll-free in the U.S.: Call 877-877-BBOX (outside U.S. call 724-746-5500) SUPPORT FREE technical support 24 hours a day, 7 days a week: Call 724-746-5500 or fax 724-746-0746 INFORMATION Mailing address: Black Box Corporation, 1000 Park Drive, Lawrence, PA 15055-1018 Web site: www.blackbox.com • E-mail: info@blackbox.com...
-
Page 4: Federal Communications Commission
FCC AND IC RFI STATEMENTS FEDERAL COMMUNICATIONS COMMISSION and INDUSTRY CANADA RADIO FREQUENCY INTERFERENCE STATEMENTS Class B Digital Device. This equipment has been tested and found to comply with the limits for a Class B computing device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. - Page 5 2- AND 4-PORT SERVSWITCH DT SERIES DVI KVM SWITCH NORMAS OFICIALES MEXICANAS (NOM) ELECTRICAL SAFETY STATEMENT INSTRUCCIONES DE SEGURIDAD 1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de que el aparato eléctrico sea operado. 2. Las instrucciones de seguridad y operación deberán ser guardadas para referencia futura.
- Page 6 NOM STATEMENT 12. Precaución debe ser tomada de tal manera que la tierra fisica y la polarización del equipo no sea eliminada. 13. Los cables de la fuente de poder deben ser guiados de tal manera que no sean pisados ni pellizcados por objetos colocados sobre o contra ellos, poniendo particular atención a los contactos y receptáculos donde salen del aparato.
- Page 7 2- AND 4-PORT SERVSWITCH DT SERIES DVI KVM SWITCH TRADEMARKS USED IN THIS MANUAL BLACK BOX, the Double Diamond logo, and ServSwitch are trademarks or registered trademarks of BB Technologies, Inc. IBM and PS/2 are registered trademarks of International Business Machines Corporation.
-
Page 8: Table Of Contents
A.1 Calling Black Box ........ -
Page 9: Specifications
2- AND 4-PORT SERVSWITCH DT SERIES DVI KVM SWITCH 1. Specifications Resolution: 1600 x 1200 @ 60 Hz Supported Operating Systems: Windows ® 95/98/Me/2000/XP and Windows NT ® Hotkeys: Yes User Controls: KV9502A: (2) port buttons (labeled 1–2) also used for KVM reset and Autoscan;... -
Page 10: Overview
CHAPTER 2: Overview 2. Overview 2.1 Introduction The 2- or 4-Port ServSwitch DT Series DVI KVM Switch allows you to control up to two or four computers from a single IBM ® console (PS/2 ® keyboard, PS/2 mouse, and DVI [Digital Visual Interface] monitor). Supported mice include Microsoft ®... -
Page 11: Components
2- AND 4-PORT SERVSWITCH DT SERIES DVI KVM SWITCH 2.2 Components 2.2.1 F RONT ANEL Figure 2-1 shows the 4-Port ServSwitch front view. Table 2-1 describes the components numbered in the illustration. ❸ ❹ POWER CPU Status CPU Select RESET SCAN ❶... -
Page 12: Rear Panel
CHAPTER 2: Overview 2.2.2 R ANEL Figure 2-2 shows the 4-Port ServSwitch rear view. Table 2-2 describes the components numbered in the illustration. ❽ ❼ ❾ ❺ ❻ Figure 2-2. The 4-Port ServSwitch back-panel view. Table 2-2. Rear-panel components. Component Description ❺... -
Page 13: What's Included
2.3 What’s Included The package should contain the following items. If anything is missing or damaged, please contact Black Box. • 2- or 4-Port ServSwitch DT Series DVI KVM Switch • (1) Universal power supply, output: 9 VDC, 600 mA •... -
Page 14: Installation
CHAPTER 3: Installation 3. Installation 3.1 ServSwitch Placement The 2- or 4-Port ServSwitch DT Series DVI KVM Switch is small, portable, and designed to fit on a desktop. Consider the following when deciding where to place the KVM switch: • How long are the cables attached to your keyboard, mouse, and monitor? •... - Page 15 2- AND 4-PORT SERVSWITCH DT SERIES DVI KVM SWITCH 2. Connect your PS/2 keyboard and PS/2 mouse directly to the 6-pin mini-DIN keyboard and mouse ports (labeled with keyboard and mouse symbols according to the KV99 standard) on the back of the ServSwitch as shown in Figure 3-1.
-
Page 16: Connecting The Computers
CHAPTER 3: Installation 3.2.2 C ONNECTING THE OMPUTERS Using the all-in-one DVI cable (EHN900024P-0006 or -0010), connect a computer to the ServSwitch. Following the KV99 standard, connect the cable’s 6-pin mini- DIN connectors to the computer’s keyboard and mouse ports. Connect the cable’s DVI-I connector to your computer’s DVI-I monitor port as shown in Figure 3-2. -
Page 17: Operation
2- AND 4-PORT SERVSWITCH DT SERIES DVI KVM SWITCH 4. Operation 4.1 Powering Up the System Once all cables have been connected and all computers have been powered on, the ServSwitch emulates mouse and keyboard signals on each port, allowing your computer to boot normally. - Page 18 CHAPTER 4: Operation Table 4-1. Hotkey commands. Command Description <Left-Ctrl><Left-Ctrl> X Switch to PC “X”. <Left-Ctrl><Left-Ctrl> <up arrow> Switch to previous active PC. <Left-Ctrl><Left-Ctrl> <down arrow> Switch to next active PC. <Left-Ctrl><Left-Ctrl> F1 Begin AutoScan. <Left-Ctrl><Left-Ctrl> F2 Manual scan. <Left-Ctrl><Left-Ctrl> F3 Set the time before switching to the next computer in sequence.
-
Page 19: Appendix. Troubleshooting
• If you are shipping the 2- or 4-Port ServSwitch DT Series DVI KVM Switch for repair, make sure you include everything that came in the original package. Before you ship, contact Black Box to get a Return Authorization (RA) number.
