Summary of Contents for Rosewill RISE
- Page 1 User’s Manual...
- Page 3 Front panel Front dust filter Front 3x 120mm fans...
-
Page 4: Accessory Box
CASE RISE User Manual Accessory Box 1 x M/B standoff socket Motherboard 3.5” HDD 21 x Screw A Motherboard 28 x Screw B 2.5” HDD/SSD 8 x Screw C 3 x Cable tie Cables © All rights reserved by Rosewill... - Page 5 -Please remember to clean the PSU dust filter regularly or insufficient air intake may fail your power supply permanently. **Unscrew to remove the cover to install the secondary PSU if necessary. © All rights reserved by Rosewill...
- Page 6 CASE RISE User Manual * Screw A -Place the motherboard onto stand-offs and secure with screws. Motherboard Compatibility Micro-ATX E-ATX © All rights reserved by Rosewill...
- Page 7 CASE RISE User Manual -Unscrew to remove expansion slot cover. -Install the add-on card into its position. -Secure with thumb screw. © All rights reserved by Rosewill...
- Page 9 *Screw B - Unscrew the screws to remove the HDD/SSD mount cover. - Screw the 3.5”/2.5” HDD/SSD onto the mount, and reinstall the cover back to the mount. - Reinstall the HDD/SSD mount into position. © All rights reserved by Rosewill...
- Page 11 CASE RISE User Manual Make sure all necessary cables and wires are connected, then reinstall side panels and secure with screws. © All rights reserved by Rosewill...
- Page 13 Please regoster your product at : http://www.rosewill.com for complete warranty information and future support for your product. If you have any question while using our products, please visit our website : www.rosewill.com for user manual or feel free to contact us.
- Page 14 www.rosewill.com...
