- Page 1 3.5” IDE / USB2.0 External Enclosure RX35-AT-IU BLK/SLV User Manual...
- Page 2 3.5” IDE/USB2.0 External Enclosure RX35-AT-IU BLK/SLV User Manual Hardware Installation Guide Note: Please refer to the pictures shown below. STEP1: Pull out the rear panel. You will see the internal structure of the external enclosure. STEP2: Insert the IDE connector into the IDE socket on the HDD.
- Page 3 3.5” IDE/USB2.0 External Enclosure RX35-AT-IU BLK/SLV User Manual STEP3: Screw the HDD to the tray tightly. STEP4: Push the tray into the aluminum case.
- Page 4 3.5” IDE/USB2.0 External Enclosure RX35-AT-IU BLK/SLV User Manual STEP5: Screw both side of the case to lock the HDD. STEP6: Screw the rear panel to the external enclosure.
- Page 5 3.5” IDE/USB2.0 External Enclosure RX35-AT-IU BLK/SLV User Manual HDD Formatting Guide ☆ You may format your external HDD through USB2.0 connection. ☆ Please make sure your external HDD is turned on and well connected to the PC before formatting the HDD.
- Page 6 3.5” IDE/USB2.0 External Enclosure RX35-AT-IU BLK/SLV User Manual STEP2: Select “Disk Management” and you will see your External HDD showed “Unallocated”. STEP3: Right-click on the “Unallocated” block and selects “New Partition”.
- Page 7 3.5” IDE/USB2.0 External Enclosure RX35-AT-IU BLK/SLV User Manual STEP4: The “New Partition Wizard” will appear. Please follow the instruction of the wizard to complete. STEP5: When new partition is completed, the external HDD will be recognized as a “New Volume”.
- Page 8 User Manual STEP6: Double-click “My Computer”. You will see the new volume appears on your PC. Thank you for purchasing a quality Rosewill Product. Please register your product at : www.rosewill.com for complete warranty information and future support for your product.
