- Page 1 External Enclosure for 3.5" SATA to USB + eSATA RX81US-HT35B-BLK User Manual...
- Page 2 External Enclosure For 3.5” SATA to USB + eSATA Please read this installation carefully before you use the products. Precaution: If it is a new HDD, needs to processing the disk partition Win98SE and WinME do not recognize NTFS formatted drives, so if you want to use your drive on those platforms, we recommend you to use FAT32 instead.
- Page 3 External Enclosure For 3.5” SATA to USB + eSATA User Manual Available Interfaces USB 2.0 + e-SERIAL ATA Protection of DC adapter a. Primary (Input) Protection The input power line will be fused with a fuse 2.0A, 250 VAC. b. Secondary (Output) protection b.1.
- Page 4 External Enclosure For 3.5” SATA to USB + eSATA Package Contents 3.5 inch external enclosure Driver Disk Installation Guide AC adapter USB cable eSATA cable Footstand Screw Kit FEATURE Standard USB 2.0 high speed transfer rate. Support Serial ATA. (USB + e-SATA) Aluminum HDD frame for easy installation.
- Page 5 External Enclosure For 3.5” SATA to USB + eSATA Technical Specifications Interfaces: Data Speeds Connectors SATA Standard Power Supply AC Input Dimensions Weight: Certification USB v 2.0 / eSATA USB 2.0 = 480 Mbps eSATA = 3.0 Gbps (NCQ Support) USB B receptacle / eSATA connectors Compliant with SATA I / II with NCQ support...
- Page 6 External Enclosure For 3.5” SATA to USB + eSATA User Manual Installation Guide 1. Pull the bottom (as fig.1) to release the HDD tray. 2. Fix the HDD by screws after HDD located with the connecter.
- Page 7 External Enclosure For 3.5” SATA to USB + eSATA 3. Aims at trail and pull in the tray into external box. 4. After connect USB / SATA and Power cable, HDD will appear the relativity. Attention: Make sure your PCI Host Card is installed correctly If required, update your OS (win 2000 to SP4, Win xp to SP1a) Only one interface at the time can be used (combo model) User Manual...
- Page 8 External Enclosure For 3.5” SATA to USB + eSATA Driver Installation: Windows 98SE After plug the external box into, the system will remind you there is a new hardware of USB Storage Adapter add into. Design the driver of the safe path (in the driver), the system will active the installation automatically.
- Page 9 External Enclosure For 3.5” SATA to USB + eSATA The divided partition of the external HDD Win 98SE/ME SYSTEM FDISK is command that doing the divided partition to HDD, The step of how to divided partition from the HDD by using FDISK as follows: Plug the cable of USB into PC, and be sure that the PC has identified HDD.
- Page 10 External Enclosure For 3.5” SATA to USB + eSATA User Manual Notice: If you want your ENCLOSURE on a Windows as well as on your Mac OS, we recommend you to use a PC to format the drive. Choose FAT32 format and do not change anything on the partition or format on your Mac, otherwise the Windows OS can not be able to recognize the enclosure.
- Page 11 If you can not see the drive, make sure the jumper settings of your hard drive is “master”. Thank you for purchasing a quality Rosewill Product. Please register your product at : www.rosewill.com for complete warranty information and future support for your product.
