3-IN-1 YARD CART
Owner's Manual
Model GOR1200X
• Important Safety Instructions
• Assembly Instructions
• Parts and Hardware Identification
CAUTION:
Read, understand and follow ALL instructions before using this product.
Questions, problems, missing parts? Before returning to your retailer, call our customer service
department at 1-800-867-6763, 9a.m. - 4p.m., CST, Monday - Friday.
For product inquiries:
Tricam
7677 Equitable Drive
Eden Prairie, MN 55344
1-800-867-6763
www.tricam.com
U.S. Patent #s 6,851,756, 7,210,697, 7,390,065 and 7,441,792 Other U.S. and Foreign Patents Pending
10/10

Advertisement

loading
Need help?

Need help?

Do you have a question about the GOR1200X and is the answer not in the manual?

Questions and answers

Summary of Contents for Gorilla Carts GOR1200X

  • Page 1 3-IN-1 YARD CART Owner’s Manual Model GOR1200X • Important Safety Instructions • Assembly Instructions • Parts and Hardware Identification CAUTION: Read, understand and follow ALL instructions before using this product. Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-800-867-6763, 9a.m.
  • Page 3: Parts List

    Exploded Drawing for Assembly Parts List A. Bed Frame (1) B. Dump Lock (1) C. Front Axle Assembly (1) D. Front Struts (2) E. Rear Axle Assembly (1) F. Rear Struts (2) G. Wheels (4) H. Handle (1) I. Bed Liner (1) J.
  • Page 4 Important Safety Instructions 1. READ ALL INSTRUCTIONS CAREFULLY BEFORE USE. If you do not understand these instructions, need clarification or further explanation, please call our toll free answer line for assistance at 1 1 - - 8 8 0 0 0 0 - - 8 8 6 6 7 7 - - 6 6 7 7 6 6 3 3 Monday through Friday 9:00 a.m.
  • Page 5 Step 3 A) Unlock the front frame and place the rear axle assembly under the frame to prop it up for easier access. B) Attach the front axle assembly to the bed frame using M8x20 carriage bolts (4), M8 washers (4), and M8 lock nuts (4). The bolts should go through the frame first then the front axle.
  • Page 6 Step 5 Attach the front struts (2) to the bed frame using M8x20 carriage bolts (2), M8 washers (2), and M8 lock nuts (2). Slide the M8x20 carriage bolt through the bed frame first and then through the struts. Hand tighten. D D o o n n o o t t f f u u l l l l y y t t i i g g h h t t e e n n b b o o l l t t s s a a t t t t h h i i s s t t i i m m e e . . Step 6 Next attach the front struts (2) to the underside of the front axle assembly using...
  • Page 7 Step 8 Slide the rear struts onto the rear axle assembly and attach the angled part of the strut to the bed frame using M8x20 carriage bolts (2), M8 washers (2), and M8 lock nuts (2). Tighten all hardware securely in Steps 7 and 8.
  • Page 8 Step 11 Attach the handle to the yoke using M8x60 carriage bolt (1), M8 washer (1), and M8 lock nut (1). Tighten securely. Step 12 Insert the liner onto the bed frame. Please reference the stamp "THIS SIDE UP" to ensure proper placement. Step 13 Attach the left and right side panels onto the bed frame by sliding each side panel post in the corner...
  • Page 9 Step 14 Attach the front and rear panels onto the bed frame by sliding each side down into the side panel track until it locks into place. LOCKED UNLOCKED N N O O T T E E : : T T h h e e f f r r o o n n t t a a n n d d r r e e a a r r p p a a n n e e l l s s m m u u s s t t b b e e r r e e m m o o v v e e d d b b e e f f o o r r e e r r e e m m o o v v i i n n g g t t h h e e s s i i d d e e p p a a n n e e l l s s . . T T h h i i s s c c a a r r t t c c a a n n n n o o t t b b e e u u s s e e d d w w i i t t h h t t h h e e f f r r o o n n t t a a n n d d r r e e a a r r p p a a n n e e l l s s o o n n l l y y .
  • Page 10 Using the Dumping Feature To operate the dumping feature, pull the dumping release handle upward to release the bed from the locking mechanism. Lift up the release handle to rotate cart upward into the dumping position. UNLOCKED Returning the Bed to the Lowered Position Rotate the bed back down to the lowered position.
