C. Measur in g Resist a n c e
Warning
To avoid harms to you, please do not atte m p t to inpu t
vol ta g e higher than 60V DC or 30V rms AC.
To avoid possibl e damag es to the Meter or to the
devi ce s under test, discon n e c t cir cu i t pow e r and
disch a r g e all the high- voltag e capa ci t o r s before
measur i n g resis ta n c e .
To measure resistance, set up the Meter as shown in
Figure 3-3 and follow the following procedure:
1. Insert the red test lead into the terminal and the
black test lead into the COM terminal.
2. Set the rotary switch to; press BLUE button
to select measurement mode.
3. Connect the test leads across with the object being
measured.
The measured value shows on the display.
The BLUE button cycles among resistance, continuity,
and diode.
34
Model UT71C/D/E: OPERATING MANUAL
Figure 3-3. Resistance Measurement
