Unpacking Inspection
Open the package case and take out the Meter. Check the items shown on Table 1-1 carefully to see any missing
or damaged part:
Item
1
English Operating Manual
2
Test Lead
3
K-Type (nickel chromium ~ nickel silicon) Point Contact Temperature Probe (It is
only suitable for measuring temperature under 230 oC
4
Alligator Clip
5
Test Clip
6
USB interface cable
7
CD-ROM (Installation Guide & Computer Interface Software)
8
Carrying Bag
9
Power Adaptor (UT71E only)
10
9V Battery (NEDA 1604, 6F22, 006P)
In the event you find any missing or damage, please contact your dealer immediately.
6
Table 1-1. Unpacking Inspection
Description
Model UT71A/B/C/D/E: OPERATING MANUAL
Qty
1 piece
1 pair
1 piece
1 piece
1 pair
1 piece
1 piece
1 piece
1 piece
1 piece
