4
OPTIONS
D BATTERY PACKS
• BP-280/BP-279/BP-278
Battery pack Voltage
BP-280
BP-279
7.2 V
BP-278
* When the Power Save function is turned ON, and the operating
periods are calculated under the following conditions:
TX : RX : standby = 5 : 5 : 90
D CHARGERS
• BC-213
desktop charger
To rapidly charge a single battery pack.
• BC-214
multi charger
To rapidly charge up to 6 battery packs.
D DC CABLES
• CP-23L
cigarette lighter cable
Enables charging the battery pack using a 12 V cigarette lighter
socket. (Use with the BC-213)
• OPC-656
dc power cable
Enables charging the battery pack using a 13.8 V power source
instead of the power adapter. (Use with the BC-214)
D ANTENNA
• FA-SC73US
stubby antenna
450–490 MHz
11
battery pack
Capacity
Battery life*
2280 mAh (minimum)
18 hours
2400 mAh (typical)
1485 mAh (minimum)
12 hours
1570 mAh (typical)
1130 mAh (minimum)
9 hours
1190 mAh (typical)
+ BC-123SV
ac adapter
+ BC-157S
ac adapter
D OTHERS
• MB-130
mobile bracket
Mounts the BC-213
desktop charger
vehicle.
• MB-133
belt clip
• HM-153LA/HM-166LA
earphone microphone
Ideal for hands-free operation. Clip the HM-153LA or HM-166LA
(with integrated PTT switch) to your lapel or breast pocket.
• HM-158LA/HM-159LA/HM-168LWP*
Combination speaker-microphone that provides convenient opera-
tion while the transceiver is hanging on your belt.
• HS-97
headset
+ VS-4LA
/OPC-2004LA
ptt switch cable
HS-97:
Throat microphone
VS-4LA:
To connect the headset
OPC-2004LA: To connect to the headset for VOX operation
- Adjust both the microphone and VOX gain before use.
• HS-94LWP*/HS-95LWP*
headset
hs-94lwp:
Ear-hook type
HS-95LWP:
Neck-arm type
- Adjust both the microphone and VOX gain before use.
* When in use, the transceiver meets IP67 requirements for dust-tight
and waterproof protection.
• CS-41PRO
cloning software
Enables quick and easy entry of settings such as RX frequencies
and Set mode contents.
Approved Icom optional equipment is designed for optimal performance when
used with an Icom transceiver. Icom is not responsible for the destruction or
damage to an Icom transceiver in the event the Icom transceiver is used with
equipment that is not manufactured or approved by Icom.
in a variety of places in a
speaker microphone
adapter cable
+ OPC-478UC
cloning cable
