INTERFACE SELECTION

Follow the procedure to configure the interface required by your
application:
- USB Interface
- RS232 Interface

USB INTERFACE CONFIGURATION

The USB interface is compatible with:
Windows 98 (and later)
Mac OS 8.0 (and later)
START-UP
As with all USB devices, upon connection, the Host performs
several checks by communicating with the Touch™reader.
Before the Touch™reader is ready to read codes, the correct
USB driver must be loaded.
For all systems, the correct USB driver for the default
USB-KBD interface is included in the Host Operating System
and will either be loaded automatically or will be suggested by
the O.S. and should therefore be selected from the dialog box
(the first time only).
You can now read codes. At this point you can read the USB
interface configuration code according to your application. Load
drivers from the O.S. (if requested). When configuring the USB-
COM interface, the relevant files and drivers must be installed
from the USB Device Installation software which can be
downloaded from the web page:
http://www.datalogic.com/services/support/.
The reader is ready.
Successive start-ups will automatically recognize the previously
loaded drivers.
First Start Up
Connect Touch™ to Host
Load drivers
(if requested)
Select desired USB interface code
(USB-KBD is default)
Load drivers
(if requested)
Read test codes.
Reader is READY
- Wedge Interface
- Pen Interface
IBM POS for Windows
4690 Operating System
