[1] ROTABROACH RAIL DRILLING MACHINE MODEL RD07A
Maximum hole cutting capacity 36mm dia.
Arbor bore 19.05mm dia. (3/4")
Engine
STIHL Model BT130
36.3cm³ displacement
On load torque 74.4Nm @ 150rpm
Fuel tank capacity 0.8 litres
Petrol/oil mix
Overall dimensions
Net Weight
Maximum hand/arm vibration magnitude
(measured at handle during operation in
accordance with ISO5349)
Estimate of likely daily vibration exposure –
Operation on 2 Rails (24 holes @ 1
minute/hole)
Average noise level during cutting at operators
ear position.
EAR DEFENDERS MUST BE WORN WHEN THE MOTOR IS RUNNING.
ANY MODIFICATIONS TO THIS MACHINE WILL INVALIDATE THE GUARANTEE
Engine Speed
No load (engine)
No load (arbor/spindle)
Normal full load (arbor/spindle)
50:1 with Stihl
25:1 other brands
Length
Width
Height
4
June 2014
9560rpm
200rpm
150rpm
500mm
420mm
450mm
19.2kgs
15.6 m/s²
2.47 m/s² A(8)
92dB(A)
