7060B / 7070A / 7071A Data Sheet
SyStem SpeciFicAtiOnS
7060B
Free field frequency response 19 Hz...85 Hz
(+/- 3 dB) LFE 85/120 Hz
Maximum short term sine wave
SPL output averaged from
30 to 85 Hz, measured in
≥ 108 dB SPL
half space at 1 meter
Maximum peak SPL output with
random pink noise, measured
≥ 113 dB SPL
in half space at 1 meter
Self generated noise level in
free field @ 1 m on axis
(A-weighted) ≤ 15 dB
Harmonic distortion @ 90 dB SPL
at @ 1 m on axis in half space 30 ... 85 Hz
≤ ≤ 3 %
2nd
3rd ≤ ≤ 2 %
Driver, magnetically shielded 250 mm (10")
Weight 26 kg (57 lbs)
Dimensions
Height 527 mm (20 3/4")
Width 462 mm (18 3/16")
Depth 363 mm (14 5/16")
crOSSOver SectiOn
7060B
Subsonic filter
(18 dB/octave) below 19 Hz
Crossover frequency,
(sub/main channels) 85 Hz
LFE cutoff Hz 85 Hz/120 Hz selectable
Crossover slopes
Lowpass 36 dB/octave
Highpass 12 dB/octave
≥ 50 dB
Midband rejection >400 Hz
Bass roll-off control operating From 0 to –6 dB @ 20 Hz
range in 2 dB steps
Phase matching control From 0 to -270° @ 85 Hz
in 90° steps
Genelec Document BBA0032001c. Copyright Genelec Oy 3.2006. All data subject to change without prior notice
7070A 7071A
19 Hz...85 Hz 19 Hz...85 Hz
LFE 85/120 Hz LFE 85/120 Hz
≥ 112 dB SPL ≥ 118 dB SPL
≥ 117 dB SPL ≥ 123 dB SPL
@ 95 dB SPL @ 100 dB SPL
30 ... 85 Hz 30 ... 85 Hz
≤ ≤ 3 % ≤ ≤ 3 %
≤ ≤ 3 % ≤ ≤ 3 %
305 mm (12") 2 x 305 mm (12")
50 kg (110 lbs) 81 kg (178 lbs)
625 mm (24 5/8") 755 mm (29 3/4")
555 mm (21 7/8") 803 mm (31 5/8")
490 mm (19 5/16") 490 mm (19 5/16")
7070A 7071A
International enquiries:
Genelec, Olvitie 5
FIN-74100, Iisalmi, Finland
Phone +358 17 83881
Fax +358 17 812 267
Email genelec@genelec.com
AmpliFier SectiOn
7060B
Short term amplifier output
power (Long term output power
is limited by driver unit
protection circuitry) 120 W
Amplifier system distortion
at nominal output
THD ≤ 0.05%
Mains voltage 100/200 V
or 115/230 V
Power consumption (average)
Idle 15 VA
Full output 150 VA
input SectiOn
7060B
Input connector XLR female
pin 1 gnd
pin 2 +
pin 3 –
Input impedance 10 kOhm balanced
Input level for 100 dB SPL
output @ 1 m Variable from +12 to –6 dBu
Output SectiOn
7060B
Output connector XLR male
pin 1 gnd
pin 2 +
pin 3 –
Remote LED connector (RJ11) Remote LED for Power/Overload+Bypass
Main monitor Out gain 0 dB
Sum Out gain 0 dB
cOntrOlS
7060B
Input sensitivity +12 to –6 dBu
Bypass Bypasses the bass management for the main channels
LFE bandwidth 85 / 120 Hz
LFE sensitivity 0 / +10 dB
Redirect Redirects LFE channel signal above 85 Hz to center channel
Sum in Changes subwoofer to Sum in mode
Test tone for phase adjustment 85 Hz
Bass roll-off 0/-2 dB/ -4 dB/ -6 dB @ 20 Hz
Phase 0/90/180/270°
In the U.S. please contact In China please contact:
Genelec, Inc., 7 Tech Circle Beijing Genelec Audio Co. Ltd.
Natick, MA 01760 Jianwai SOHO, Tower 12, Room 2306
Phone +1 508 652 0900 39 East 3rd Ring Road
Chaoyang District
Fax +1 508 652 0909
Email genelec.usa@genelec.com Beijing 100022, China
Phone +86 10 5869 7915,
Fax +86 10 5869 7914
7070A 7071A
250 W 500 W
15 VA 30 VA
250 VA 500 VA
7070A 7071A
7070A 7071A
7070A 7071A
