7040A Operating Manual
SYSTEM SPECIFICATIONS
Free field frequency response (-6 dB)
Accuracy of frequency response
Maximum short term sine wave SPL output
averaged from 40 to 85 Hz, measured in half
space at 1 meter
Self generated noise level in half space at
1 m (A-weighted)
Harmonic distortion at 90 dB SPL
at 1 m on axis in half space 40...85 Hz
2nd
3rd
Driver, magnetically shielded
Weight
Dimensions
Height
Width
Depth
CROSSOVER SECTION
Subsonic filter (18 dB/octave) below
Input channels
Low pass frequency for main channels
Midband rejection >400 Hz
Bass Roll-Off control in 2 dB steps
Phase matching control in 90° steps
Input sensitivity control
Genelec Document D0126R001 Copyright Genelec Oy 3.2015. All data subject to change without prior notice
7040A
30...90 Hz
± 3 dB (33...85 Hz)
100 dB
≤ 5 dB
≤ 2.5%
≤ 1.5 %
165 mm (6 / in)
1
2
11.3 kg (24.9 lb)
410 mm (16 / in)
1
8
350 mm (13 3 / in)
4
205 mm (8 / in)
1
16
7040A
35 Hz
2
85 Hz
≥ 50 dB
0 to -6 dB @ 35 Hz
0 to -270°
+12 to -6 dBu
International enquiries:
In the U.S. please contact:
Genelec, Olvitie 5
Genelec, Inc., 7 Tech Circle
FIN-74100, Iisalmi, Finland
Natick, MA 01760, USA
Phone +358 17 83881 Phone +1 508 652 0900
Fax +358 17 812 267 Fax +1 508 652 0909
Email genelec@genelec.com
Email genelec.usa@genelec.com
AMPLIFIER SECTION
Amplifier short term output power
(Long term output power is limited by driver
unit protection circuitry)
Amplifier system THD at nominal output
Mains voltage
Power consumption (average)
Standby (ISS active)
Idle
Full output
INPUT SECTION
Input connectors XLR female
pin 1
pin 2
pin 3
Input impedance
Input level for 100 dB SPL output @ 1 m
OUTPUT SECTION
Input connectors XLR male
pin 1
pin 2
pin 3
Main monitor Out gain
In China please contact:
Beijing Genelec Audio Co.Ltd
Room 101, 1st floor, Building 71 B33
Universal Business Park, No. 10 Jiuxianqiao Road
Chaoyang District, Beijing, China
Phone +86 (10) 5823 2014
Post code: 100015
Email genelec.china@genelec.com
7040A
50 W
≤ 0.08 %
100 - 240 VAC universal
≤ 0.5 W
5 W
70 W
7040A
gnd
+
-
10 kohm balanced
Variable from +12 to -6
dBu
7040A
gnd
+
-
0 dB
