Meet at a designated outdoor location.
Emphasize that no one should return to the premises if
there is a fire.
Notify fire department from a neighbor's phone.
!
WARNING
If you arrive at the premises and hear sirens, do
not attempt to enter the building. Call for emer-
gency assistance from a neighbor's phone.

Floor Plan Example

Figure 10 is an example of a multilevel floor plan. Use it as
a guide and draw your floor plan on the next page.
SMOKE ALARMS/DETECTORS FOR MINIMUM PROTECTION
SMOKE ALARMS/DETECTORS FOR ADDITIONAL PROTECTION
ATTIC HEAT ACTIVATED ALARMS/DETECTORS
A smoke detector should
BEDROOM BEDROOM
be located on each level.
LIVING
KITCHEN
ROOM
BASEMENT
DINING
KITCHEN BEDROOM BEDROOM
ROOM
LIVING
ROOM BATH BEDROOM
TV DINING
KITCHEN BEDROOM
ROOM
ROOM
BATH
LIVING
ROOM BEDROOM
BEDROOM
Figure 10.Examples of a floor plans.
System Sensor™ Smoke Sensor Model 2100ARFT
BEDROOM BEDROOM
LIVING
ROOM
RECREATION
ROOM
BASEMENT
Smoke detectors should be located
between the sleeping area and the
rest of the family living unit.
In family living units with more than
one sleeping area, locate a smoke
detector at each area.

Your Floor Plan

When establishing your escape routes, consider the
following guidelines:
Show all building levels.
Show all exits, (two exits per room are recommended).
Show the location of all components of the fire system.
Show the locations of any fire extinguishers, hoses,
ladders, etc.
Emergencies
5
