- Page 1 Digital Substrobe Fuel Gauge Ful l Tes t Ready Li ght w / Li t e DS160 4060.1 Note: Please read all instructions before using this product.
-
Page 2: Table Of Contents
SMART CHARGER 4067.1 ....19 Strobe Power ........4 Smart Charger 4067.1 ......19 DS160 Substrobe ........5 Smart Charger Components ....19 Overview of DS160 Features ....5 Smart Charger Indicator Light....19 Charging with NiMH Charger ....19 Becoming Familiar ......5 CAUTION ..........19 OPENING AND CLOSING ....6 RECOMMENDATIONS......20... -
Page 3: Ikelite Ds161 Substrobe
IKELITE DS160 SUBSTROBE DS160 SPECIFICATIONS CE - Compliant with applicable EU directives Complies with FCC part 15, subpart B, Section 15.109 for Class “B” Products S p e c i f i c a t i o n s Battery Pack ........... Li-ion module, 7.4v, 4500mAh Weight ............ -
Page 4: Introduction
STROBE POWER The DS160 recycles in a quick 1.4 sec from full discharge. When fired at a fractional power — whether in TTL or manual mode — the strobe recycles virtually instantaneously. Number of flashes per full charge will increase dramatically in most cases when using in TTL mode with a compatible camera system. -
Page 5: Ds160 Substrobe
We recommend that you become familiar with the features and functions of the Ikelite Substrobe before trying the camera and strobe in the water. If you have not done so, we also suggest reading your camera owner's manual. -
Page 6: Opening And Closing
The Li-ion batteries remain permanently secured inside the pack. The front section of the DS160, which houses the main electronics, is safely sealed separately from the Li-ion pack. The front section will remain waterproof when the Li-ion pack is removed. -
Page 7: Opening And Closing (Illustrations)
OPENING AND CLOSING (CONT.) Pull Out Flip Up Rotate... -
Page 8: Li-Ion Battery Pack
DO NOT disassemble the Li-ion pack or charger. The DS160 accepts the same 4066.5 NiMH module used on older DS161, DS160 and DS125 Substrobes. If you intend to use an older battery pack on your new Substrobe, please reference the notice dated 6/22/09 on the following webpage: http://www.ikelite.com/web_pages/important.html. -
Page 9: Flash Diffuser
FLASH DIFFUSER 0591.3 USING THE DIFFUSER The white diffuser can be secured to the front of the DS160 strobe when softer lighting or a coverage angle of 100° is desired. The diffuser reduces the DS160’s light intensity by one full f-stop. -
Page 10: Arm Systems/Strobe Mounts
ARM SYSTEMS / STROBE MOUNTS IKELITE ARM SYSTEMS Ikelite offers several arm choices compatible with the DS160. The arm and strobe mount are NOT supplied with the strobe. For additional information go to www.ikelite.com Caution: Ikelite arm systems are designed for underwater use. Be careful when transporting the system above water since some camera trays and arm adjustments may be unable to support the weight of the strobe(s) above water. -
Page 11: Strobe Connection
EV manual controller sensor to be connected to the strobe. The sync cord or sensor relays a signal from the camera to the substrobe that tells the DS160 when to flash. The removable waterproof bulkhead cap seals the bulkhead connector when neither a cord nor a sensor is connected to the DS160. -
Page 12: Strobe Connection (Illustration)
STROBE CONNECTION (CONT.) DS160 Strobe Bulkhead Connection Bulkhead Cap Stem O-ring Retaining Ring Blue Band #4103.51 Ikelite Sync Cord... -
Page 13: Using As Hard-Wired Strobe Without Ttl
- Non-Ikelite housings for digital cameras with Nikonos-style strobe connector Connect the strobe using an appropriate Ikelite sync cord. The DS160 must be used in manual exposure modes. Strobe output is not automatically adjusted for proper exposure when set to TTL(Auto) mode. -
Page 14: Using As A Slave Strobe
Both the EV Manual Controller and the Substrobe DS160 are preflash compatible. The internal switches on the EV Controller must be set properly for the DS160 to fire at the correct time. Refer to the EV Manual Controller instruction manual for more information. -
Page 15: Aiming The Strobe
When using auto-focus cameras, the modeling light may be required in low light levels to illuminate your subject to allow the camera to auto focus. DS160 Strobe Flash Tube Modeling Light... -
Page 16: Switches / Fuel Gauge
SWITCHES / FUEL GAUGE The DS160 features separate switches for power on/off and firing modes. The arrow on the switch points to the selected position. ON/OFF SWITCH OFF: The horizontal switch position is OFF. The adjacent tab locks the switch in the OFF position. -
Page 17: Fuel Gauge
No LED - less then 25% CONFIDENCE SIGNAL The DS160 strobe features a confidence signal indicator light that will glow if the strobe properly exposes the picture. The #3 LED on the fuel gauge will glow GREEN for three seconds if the DS160 strobe quenches, indicating that the strobe has provided proper exposure. -
Page 18: Strobe Ready Light
STR OBE RE A DY L IG HT STROBE READY LIGHT AND TTL HOUSING The Ikelite DS160 Substrobe features a ready light that glows red when the DS160 has recycled and is ready to fire its flash again. The middle #2 LED on the fuel gauge functions as the visual ready light. -
Page 19: Smart Charger 4067.1
It provides more complete recharging and prolongs battery life. Charging Time The Smart Charger will fully recharge the DS160 battery pack in 5 hours. Smart Charger Components The Smart Charger offers use worldwide by accepting interchangeable adapter plugs for different electric wall outlets. -
Page 20: Recommendations
Weak batteries are the cause of many strobe and camera problems. • Do not fire the strobe more than 15 times above water in rapid succession. If this does happen, allow the DS160 to cool off for at least 10 minutes before resuming photography. LUBRICANT •... -
Page 21: Maintenance
Afterwards, lightly lubricate them. The o-ring 0132.36 is located on the inside rim of the DS160 battery pack. Keep the o-ring and the sealing surfaces clean. DO NOT stretch the o-ring when cleaning. -
Page 22: Troubleshooting
If the DS160 flashes, the source of the problem lies somewhere in the camera. If the DS160 does not flash, please send both the strobe and cord used in the test to an authorized Ikelite dealer, or to Ikelite; see “Return Product for Service” on page 23. -
Page 23: Flooding
Defective products should be returned prepaid to Ikelite. Ikelite will, at its discretion, repair or replace such products, and will return them to the customer prepaid. All other claims, of any nature, including, but not limited to, bulb failure, are not covered. -
Page 24: Product Registration
PRODUCT REGISTRATION Please visit www.ikelite.com to register your Ikelite Digital Substrobe within 15 days of purchase. Ikelite Underwater Systems 50 West 33rd Street Indianapolis, IN 46208 USA www.ikelite.com 317-923-4523 DS160 Substrobe_4060.1-01-1212...
