P6F94 Quick Reference
R
int e l
Pentium II CPU Soft-Menu(Jumperless) Settings
1) Turn the system on, then press <DEL> key to access the AWARD BIOS
SETUP program. A "CMOS SETUP UTILITY" will display on the screen.
Select "LOAD SETUP DEFAULTS" and type "Y" to load BIOS optimal
setup.
2) After the BIOS optimal setting is set, at the top right hand side of the
"Chipset Feature Setup" screen, there is a "CPU Speed" option. Refer
to the table below and select the correct CPU speed.
CPU SPEED
233MHz
266MHz
300MHz
333MHz
3) Select "STANDARD CMOS SETUP" to set the Date /Time, Floppy drive
type, and set Hard Disk Type to "Auto".
4) Select "SAVE & EXIT SETUP" and press the <Enter> key to save the set-
ting information in the CMOS memory and continue with the booting pro-
cess.
Soft-Menu Setting
66.6MHz
3.5
66.6MHz
4.0
66.6MHz
4.5
66.6MHz
5.0
FILE NAME:
F94x.DOC
062798
