  • Page 1 P6F117 Mainboard Manual Friday, March 02, 2001...
  • Page 3 Copyright Notice ©Copyright 2000 The information contained in this user’s manual and all accompany- ing documentation is copyrighted and all rights are reserved. This publication may not, in whole or in part, be reproduced, transcribed, stored in a retrieval system, translated into any language or com- puter language, or transmitted in any form whatsoever without the prior written consent from the manufacturer, except for copies re- tained by the purchasers for their personal archival purposes.
  • Page 4 Preface Using This Manual This manual is designed to help you build a reliable Personal Com- puter based on the P6F117 platform. Chapter 1—Quick Reference This chapter is for advanced users who want to quickly assemble a system. The mainboard layout along with jumper and switch settings, and memory configuration are provided.

  • Page 5: Table Of Contents

    Preface Table of Contents 1. P6F117 QUICK REFERENCE 1.1. Mainboard Layout............1 1.2. I/O Ports ................2 1.3. Panel Connector ............2 1.4. Jumpers.................3 1.5. PCI and AGP Frequency Settings........3 1.6. Connectors..............3 1.7. Memory Installation............4 2. INTRODUCTION 2.1. Overview................5 2.2. Mainboard Specifications and Features ......6 2.2.1.
  • Page 6 Preface 3.6.5. Setting Jumpers ................27 3.6.6. Auto Power On .................28 4. BIOS CONFIGURATION 4.1. Entering Setup.............30 4.2. Standard CMOS Setup ..........32 4.3. BIOS Features Setup...........36 4.4. Chipset Features Setup ..........39 4.5. Integrated Peripherals..........43 4.6. Power Management.............47 4.7. PnP/PCI Configuration..........52 4.8. PC Health Status Option..........54 4.9.

  • Page 7: P6F117 Quick Reference

    1. P6F117 Quick Reference This section is for users to get started using the mainboard straight away. 1.1. Mainboard Layout PS/2 POWER1 mouse/keyboard ports ports Parallel serial ports Game audio ports IDE1 IDE2 PCI1 USB2 PCI2 PCI3 JP19 PCI4 PCI5...

  • Page 8: I/O Ports

    Mainboard User’s Manual 1.2. I/O Ports Parallel port (LPT1) PS/2 Game port Line-out mouse Line-in ports PS/2 Microphone keyboard Serial port Serial port COM 1 COM 2 1.3. Panel Connector The following illustration shows the front panel connector pin as- signments: Ground Ground...

  • Page 9: Jumpers

    P6F117 Quick Reference 1.4. Jumpers 1-2: Normal Mode 2-3: Clear CMOS RAM JP17 1-2: OnChip sound disabled 2-3: OnChip sound enabled JP19 1-2: Suspend to RAM disabled 2-3: Suspend to RAM enabled 1-2, 3-4, 5-6, 7-8: CPU ratio = 2X 1-2, 3-4, 7-8: CPU ratio = 2.5X...

  • Page 10: Memory Installation

    Mainboard User’s Manual 1.7. Memory Installation 168-Pin DIMM SDRAM Memory Configuration Bank 0 (DIMM1) 8, 16, 32, 64, 128, 256, 512 MB Bank 1 (DIMM2) 8, 16, 32, 64, 128, 256, 512 MB Bank 2 (DIMM3) 8, 16, 32, 64, 128, 256, 512 MB Total 8 MB to 1.5 GB This concludes Chapter 1.

  • Page 11: Introduction

    2. Introduction 2.1. Overview The P6F117 is a high quality, high performance, enhanced function mainboard that supports 64-bit Intel Celeron/Cyrix Socket 370 proc- essors. This mainboard is designed around the latest and fastest Apollo Pro133A chipset in a standard ATX form factor.

  • Page 12: Mainboard Specifications And Features

    Mainboard User’s Manual 2.2. Mainboard Specifications and Features 2.2.1. Hardware Socket 370 processors Onboard Voltage Regulator Module Provides 1.3V to 3.5V operating voltage Coprocessor CPU has built-in floating point unit Speed System bus clock 66/100/133 MHz AGP clock 66 MHz PCI bus clock 33 MHz ISA bus clock 8.33~9.35 MHz Chipset...

  • Page 13: Software

    Introduction Expansion One AGP-4X (V2.0) slot Slots Five 32-bit PCI slots One 8/16-bit ISA slot Power Compliant with EPA, APM 1.2 and ACPI Management ATX soft-off power control Power – on by keyboard and PS/2 mouse Power – on by external modem ring Power –...

  • Page 14: Environment

    Mainboard User’s Manual 2.2.3. Environment Ambient Temperature 0ºC to 50ºC (operating) Relative Humidity 0 to 85% (operating) Vibration 0 to 500 Hz DC Voltage 4.9V to 5.2V DC Voltage 1.3V to 3.50V DC Voltage -5V, +12V, -12V, +5V 5% tolerance 2.3.
  • Page 15 Introduction Note: Because of optional items and design changes, your mainboard may not be identical to the one shown in the illus- tration. Key to Mainboard Components Name Function PGA370 CPU socket POWER ATX power connector DIMM1~3 Memory module slots Floppy drive connector CPU FAN CPU cooling fan connector...

  • Page 16: Microprocessor

    2.5. CPU Packaging PGA370 CPUs are packaged in a PPGA (Integrated Circuit-Plastic Pin Grid Array) configuration. 2.6. Chipset The P6F117 supports the VIA 82C694X Apollo Pro-133A chipset. The chipset comes in pairs—the North Bridge chip and the South Bridge chip. •...
  • Page 17 Introduction • Southbridge Interface between the PCI and ISA buses • Power Management Logic • USB controller • EIDE controller (ATA33/66/100) • Seven DMA channels • One timer/counter • Two 8-channel interrupt controllers • NMI logic and SMI interrupt logic •...

  • Page 18: Hardware Installation

    Of course, you can use the system I/O ports and expansion slots to add many more features and components to your system than the items listed above. 3.1. Unpacking The P6F117 mainboard package contains the following items: q One mainboard q One IDE 40-pin ribbon cable q One floppy 34-pin ribbon cable...

  • Page 19: Installation

    Hardware Installation 3.2. Installation The P6F117 is designed to fit into a standard ATX form factor chas- sis. The pattern of the mounting holes and the position of the back panel connectors meet the ATX system board specification. The chassis comes with various mounting fasteners, which are made of metal or plastic.

  • Page 20: Connector/Jumper Location

    Mainboard User’s Manual 3.4. Connector/Jumper Location POWER1 IDE1 IDE2 PCI1 USB2 PCI2 PCI3 JP19 PCI4 PCI5 Connector/Jumper Location...

  • Page 21: Attaching Connectors

    Hardware Installation 3.5. Attaching Connectors 3.5.1. Front Panel Connectors There are six connectors on the mainboard for speaker, switches, and indicator lights on the system’s front panel. Front Panel Connectors Ground Ground POWER SWITCH Power on/off Keylock POWER LED & KEYLOCK LED anode RESET N o n...

  • Page 22: Infrared (Ir) Connectors

    Mainboard User’s Manual 3.5.2. Infrared (IR) Connectors This 5-pin connector connects to an optional wireless transmitting and receiving infrared module via a cable and a bracket. Configure BIOS to enable the IrDA port if you attach an infrared module to this connector.

  • Page 23: Wake On Lan/Modem Connectors

    Hardware Installation 3.5.4. Wake on LAN/Modem Connectors These 3-pin headers are used for remote wake up of the computer through a network or modem signal. Wake On Modem Connector WOM1 Pin 1 Wake On LAN Connector WOL1 Pin 1 Note: You must enable the Wake On LAN/Wake On Modem features in the BIOS setup if you use this feature.

  • Page 24: Ide Connectors

    Mainboard User’s Manual 3.5.6. IDE Connectors An IDE drive ribbon cable has two connectors to support two IDE drives. If a ribbon cable connects to two IDE drives at the same time, one of them has to be configured as Master and the other has to be configured as Slave by setting the drive select jumpers on the drive.

  • Page 25: Back Panel Connectors

    Hardware Installation 3.5.8. Back Panel Connectors The back panel provides external access to PS/2 style keyboard and mouse connectors, two serial ports, one parallel port, dual USB ports, a game port and audio ports which are integrated on the mainboard. The figures below show the location of the back panel I/O connec- tors.
  • Page 26 Mainboard User’s Manual Parallel Port Connect a printer or other parallel device to the burgundy-colored 25-pin parallel port. You can set the parallel port IRQ and parallel port mode in BIOS. Refer to Integrated Peripherals in Chapter 4 for details. Parallel Port Serial Ports Connect a serial device such as a mouse or modem to the turquoise 9-...
  • Page 27 Hardware Installation Audio Port Connectors You can connect various audio devices to these audio jacks. Connect headphones or powered speakers to the lime-colored lineout connec- tor. Connect a tape player or another audio source to the light blue Line-in connector to record audio on your computer or to play audio through your computer’s sound chip and speakers.
  • Page 28 Mainboard User’s Manual CPU/System Fan Power Supplies There are two fan connectors on the mainboard for the cooling fans. The connectors support fans of 12V DC/500mAMP (six watt) or less. When the system goes into sleep state, fans should be shut down to eliminate audible noise and reduce power consumption.

  • Page 29: Installing The Cpu

    Hardware Installation 3.6. Installing the CPU 3.6.1. Before You Begin Be sure that your processor kit includes the following items: ♦ One processor with the fan or heat sink attached ♦ One power cable (for CPU with cooling fan attached) Place the mainboard on a workbench (not in a chassis).

  • Page 30: Removing The Processor

    Mainboard User’s Manual Identify the pin-1 corner of the PGA370. The pin-1 corner is on the same side as the locking lever, as shown in the il- lustration below. Identify the pin-1 corner of the processor (the pin-1 corner on the processor has a beveled edge). Socket Lever Processor Pin-1...

  • Page 31: Installing System Memory

    Hardware Installation 3.6.4. Installing System Memory Maximum system memory supported by the mainboard is 1.5 GB. The mainboard has three DIMM Sockets. Memory can be installed using 168-pin SDRAM DIMM memory modules. There are no jumper settings required for the memory size or type, which is auto- matically detected by the BIOS.
  • Page 32 Mainboard User’s Manual Due to the high-speed design of the mainboard, the memory modules must meet the following requirements: DRAM TYPE SDRAM (Synchronous DRAM) Module Size Single Sided Asymmetric 1Mx64, 4Mx64, 8Mx64, 16Mx64 Double-Sided Asymmetric 2Mx64, 4Mx64, 8Mx64, 16Mx64, 32Mx64 Requirements SDRAM Extended Data Output...

  • Page 33: Setting Jumpers

    Hardware Installation 3.6.5. Setting Jumpers Refer to the following illustration and instructions to set the jumpers on your mainboard. FSB Speed Settings Pin 1 OnChip Sound Settings JP17 Pin 1 CPU Clock Ratio Settings Pin 1 Suspend To RAM Settings JP19 Pin 1 Clear CMOS/Password Settings...

  • Page 34: Auto Power On

    Mainboard User’s Manual Clear CMOS/Password Jumper You may need to clear the CMOS if your system cannot boot up be- cause you forgot your password, the CPU clock setup is incorrect, or the CMOS settings need to be reset to default values after the system BIOS has been updated.

  • Page 35: Bios Configuration

    4. BIOS Configuration After the hardware configuration of the mainboard is finished, and the system hardware has been assembled, the system may be pow- ered up. At this point, CMOS setup should be run to ensure that system information is correct. The mainboard employs the latest Award BIOS CMOS chip with support for Windows Plug and Play.

  • Page 36: Entering Setup

    Mainboard User’s Manual This program should be executed under the following conditions: • When changing the system configuration • When a configuration error is detected by the system and you are prompted to make changes to the Setup program • When resetting the system clock •...
  • Page 37 BIOS Configuration After the POST routines are completed, the following message ap- pears: “Press DEL to enter SETUP” To access the AWARD BIOS SETUP program, press the <DEL> key to display the “CMOS SETUP UTILITY” screen: CMOS Setup Utility – Copyright (C) 1984 – 2000 Award Software Standard CMOS Features Frequency/Volta ge Control Load Optimized Defaults...

  • Page 38: Standard Cmos Setup

    Mainboard User’s Manual 4.2. Standard CMOS Setup Standard CMOS Setup is the same for all three chipsets. Selecting “STANDARD CMOS SETUP “on the main program screen displays the following menu: CMOS Setup Utility – Copyright (C) 1984 – 2000 Award Software Standard CMOS Features Date (mm:dd:yy) Tue, July 11 2000...
  • Page 39 BIOS Configuration CMOS Setup Utility – Copyright © 1984 – 2000 Award Software IDE Primary Master IDE HDD Auto-Detection Press Enter Item Help IDE Primary Master Auto Menu Level Access Mode Auto To auto-detect the Capacity 0 MB HDD’s size, head . . . on Cylinder this channel Head...
  • Page 40 Mainboard User’s Manual IDE Primary/Secondary Master/Slave: If you leave this item at “Auto,” the system will automatically detect and configure any IDE devices it finds. If it fails to find a hard disk, change the value to “Manual” and then manually configure the drive by entering the characteristics of the drive in the i t ems below (Capacity, Cylinder, Head, Precomp, etc.).
  • Page 41 BIOS Configuration Halt On: This setting determines which type of errors will cause the system to halt during bootup. The options are: • All Errors • No Errors • All, But Keyboard (default) • All, But Diskette • All, But Disk/Key Base/Extended/Total Memory: These items are automatically de- tected by the system at start up time.

  • Page 42: Bios Features Setup

    Mainboard User’s Manual 4.3. BIOS Features Setup Selecting “BIOS Features Setup” on the main program screen dis- plays this menu, which allows you to define advanced information about your system. You can make modifications to most of these items without introducing fatal errors to your system. Note that the page has a scroll-bar to scroll down to more items.
  • Page 43 BIOS Configuration External Cache: This setting enables the Level 2 cache. The default setting is “Enabled.” CPU L2 Cache ECC Checking: This item enables or disables ECC (Error Correction Code) e rror checking on the CPU cache memory. The default setting is “Disabled.” Processor Number Feature: Some new processors are installed with a unique processor number.
  • Page 44 Mainboard User’s Manual Gate A20 Option: This option accesses memory above 1 MB using the fast gate A20 line when set to “Fast” (default). The other option is “Normal.” Typematic Rate Setting: If set to “Enabled,” enables you to set the Typematic Rate and Typematic Delay.

  • Page 45: Chipset Features Setup

    BIOS Configuration 4.4. Chipset Features Setup Selecting “Chipset Features Setup” on the main program screen dis- plays this menu: CMOS Setup Utility – Copyright (C) 1984 – 2000 Award Software Advanced Chipset Features Bank 0/1 DRAM Timing SDRAM 10ns Item Help Bank 2/3 DRAM Timing SDRAM 10ns Bank 4/5 DRAM Timing...
  • Page 46 Mainboard User’s Manual Bank 0/1 2/3 4/5 DRAM Timing: This item allows you to select the value in the field, depending on whether the board has paged DRAMs or EDO (extended data output) DRAMs. The following op- tions are allowed: •...
  • Page 47 BIOS Configuration AGP-4X Mode: This item allows you to enable or disable the cach- ing of display data for the video memory of the processor. Enabling can greatly improve the display speed. If your graphics display card does not support this feature, you need to disable this item. The de- fault is “Enabled.”...
  • Page 48 Mainboard User’s Manual PCI Delay Transaction: The chipset has an embedded 32-bit posted write buffer to support delay transactions cycles. Enable to support compliance with PCI specification version 2.1. The default is “En- abled.” PCI#2 Access #1 Retry: When enabled, the AGP Bus (PCI#1) ac- cess to PCI Bus (PCI#2) is executed with the error retry feature.

  • Page 49: Integrated Peripherals

    BIOS Configuration 4.5. Integrated Peripherals Selecting “Integrated Peripherals” on the main program screen dis- plays this menu: CMOS Setup Utility – Copyright (C) 1984 – 2000 Award Software Integrated Peripherals On-Chip IDE Channel0 Enabled Item Help On-Chip IDE Channel1 Enabled IDE Prefetch Mode Enabled Menu Level...
  • Page 50 Mainboard User’s Manual manually to a lower mode, e.g., from Mode 3 to Mode 2. All IDE drives should work with PIO mode 0. There are six options: • Auto (default) • Mode 0 • Mode 1 • Mode 2 •...
  • Page 51 BIOS Configuration IR Function Duplex: This field is available when UART 2 Mode is set to either ASKIR or HPSIR. This item enables you to determine the infrared (IR) function of the onboard infrared chip. Full-duplex means that you can transmit and send information simultaneously. Half duplex (default) is the transmission of data in both directions, but only one direction at a time.
  • Page 52 Mainboard User’s Manual SB I/O Base Address: This item lets you set the I/O base address for the Sound Blaster card. There are four options: • 220H (default) • 240H • 260H • 280H SB IRQ Select: This item lets you set the Interrupt Request (IRQ) for the Sound Blaster card.

  • Page 53: Power Management

    BIOS Configuration 4.6. Power Management Power Management Setup controls the mainboard’s “Green” fea- tures. Selecting “Power Management Setup” on the main program screen displays this menu: CMOS Setup Utility – Copyright (C) 1984 – 2000 Award Software Power Management Setup ACPI Function Enabled Item Help...
  • Page 54 Mainboard User’s Manual Power Management: This item enables you to choose the type of Power Management you want. Selecting Power Management and pressing <Enter> displays the following screen: CMOS Setup Utility – Copyright (C) 1984 – 2000 Award Software Power Management Power Management User Define Item Help...
  • Page 55 BIOS Configuration ACPI Suspend Type: Use this item to define how your system sus- pends. In the default, S1(POS), the suspend mode is equivalent to a software power down. If you select S3 (STR), the suspend mode is a suspend to RAM – the system shuts down with the exception of a re- fresh current to the system memory.
  • Page 56 Mainboard User’s Manual Wake Up Events: This item opens a submenu that enables you to set events that will resume the system from a power saving mode. Select Wake Up Events and press <Enter> to display the following menu: CMOS Setup Utility – Copyright (C) 1984 – 2000 Award Software Wake Up Events Item Help LPT &...
  • Page 57 BIOS Configuration Primary INTR: This item opens a submenu that enables you to set IRQs that will resume the system from a power saving mode. Select IRQs Activity Monitoring and press <Enter> to display the following menu: CMOS Setup Utility – Copyright (C) 1984 – 2000 Award Software IRQs Activity Monitoring IRQ 3 (COM2)

  • Page 58: Pnp/Pci Configuration

    Mainboard User’s Manual 4.7. PnP/PCI Configuration Both the ISA and PCI buses on the Mainboard use system IRQs (In- terrupt ReQuests) and DMAs (Direct Memory Access). You must set up the IRQ and DMA assignments correctly through the PnP/PCI Configuration Setup utility; otherwise, the mainboard will not work properly.
  • Page 59 BIOS Configuration Reset Configuration Data: The system BIOS supports the Plug and Play feature so the resources assigned to each peripheral have to be recorded to prevent them from conflicting. The location to store the assigned resources is called ESCD (Extended System Configuration Data) which is located in the system flash EEPROM.

  • Page 60: Pc Health Status Option

    Mainboard User’s Manual 4.8. PC Health Status Option On mainboards that support hardware monitoring, this item lets you monitor the parameters for critical voltages, critical temperatures, and fan speeds. Selecting “PC Health Status” on the main program screen displays this menu: CMOS Setup Utility –...

  • Page 61: Frequency/Voltage Control

    BIOS Configuration System Component Characteristics: These fields provide you with information about the systems current operating status. You cannot make changes to these fields. The following information is displayed: • CPU temperature • System temperature • CPU FAN speed (in RPMs) •...
  • Page 62 Mainboard User’s Manual Spread Spectrum Modulated: If you enable spread spectrum, it can significantly reduce the EMI (Electro-Magnetic Interference) gener- ated by the system. CPU Host/PCI Clock: This item can be used to set the system bus frequency for the installed processor. The options are: •...

  • Page 63: Load Optimized Defaults Option

    BIOS Configuration 4.10. Load Optimized Defaults Option This option opens a dialog box that lets you install optimized defaults for all appropriate items in the whole Setup Utility. Press the <Y> key and then <Enter> to install the defaults. Press the <N> key and then <Enter>...

  • Page 64: Save & Exit Setup

    Mainboard User’s Manual 4.12.Save & Exit Setup Selecting this option and pressing <Enter> will save the new setting information in the CMOS memory and continue with the booting process. 4.13.Exit Without Saving Selecting this option and pressing <Enter> will exit the Setup Utility without recording any new values or changing old ones.

  • Page 65: Driver And Utility

    5. Driver and Utility 5.1. Flash Utility The BIOS of the P6F117 mainboard can be upgraded by using a Flash utility. A new version of the BIOS can be downloaded from the factory's BBS and Web site. The system BIOS is stored in a 1 M-bit Flash EEPROM that can be erased and reprogrammed by the Flash utility.

  • Page 66: System Environment Monitor

    Mainboard User’s Manual 5.3. System Environment Monitor The System Environment Monitoring utility along with the onboard VT82C686A system monitor chip enables you to monitor your sys- tem’s operating characteristics such as temperature, fan speed and CPU voltage. Using this utility, you can define the upper and lower limits of these monitored parameters.

  • Page 67: Setting The Threshold

    Driver and Utility Click on the “VIA Hardware Monitor System” icon to ac- cess the program. 5.3.2. Setting the Threshold Set the threshold for system temperature, voltages and fan speeds. System Environment Monitor...

  • Page 68: Ata66/100 Controller Options

    Mainboard User’s Manual 5.4. ATA66/100 Controller Options When using the ATA66/100 controller, the BIOS setting will allow users to “Set Device Mode” and “Select Boot Sequence.” Setting Device Mode: Choose UDMA (0~4), PIO (0~4), and MW DMA (0~2) setting options transfer mode for any hard disks (ATA66) controlled by VT82C686A, (ATA100) controlled by VT82C686B.

  • Page 69: Online Services

    Driver and Utility 5.6. Online Services Flexus Computer Technology, under the Freetech brand name, has consistently won recognition for excellence in the design and manu- facturing of high quality mainboards! Our products are globally recognized among the leading cost- performance mainboards in the industry today and we are a certified...
