Adjusting the Feet

Using the fitted adjustable feet is MANDATORY. For safety reasons and to ensure adequate ventilation, the
cooker chassis MUST NOT sit directly on the floor, a plinth, or other support surface.
Level the cooker by screwing the bottom of the feet in or out, as shown.

Moving the Cooker

• Two people must always raise the cooker, as shown, to
prevent damaging the adjustable feet.
• Do not lift the cooker by the door handles.
• DO NOT DRAG the cooker. Lift the feet clear of the floor.

Stability Bracket

The supplied stability brackets or a recognized cooker stability device must be fitted to ensure cooker remains
stable in all situations.
Screw
Washer
CFSE10WH_SV_final110426_flo.indd 15
Plastic Foot
Stability Bracket
Wall Plug
