Summary of Contents for CAS FW500-E
-
Page 2: Table Of Contents
CONTENTS ........... 4 PRECAUTIONS ..............6 PREFACE ......7 NAMES AND FUNCTIONS ............9 OPERATIONS 1. Simple Weighing Mode ........9 2. Weighing with Tare ..........9 3. Changing Unit of Weight ......... 10 4. Hold Function ............ 10 5. How to Set Auto Power Off ......11 6. -
Page 3: Precautions
PRECAUTIONS... - Page 4 PRECAUTIONS...
-
Page 5: Preface
PREFACE Thank you for purchasing CAS FW500 Series. These series have been designed with CAS reliability, under rigid quality control and with outstanding performance. Your special departments can enjoy these high quality reliable CAS products. We believe that your needs will be satisfied and you will have proper reliability. - Page 6 DISPLAY & KEYBOARD ■ FW500-C (LCD Ver.) ■ FW500-E (LED Ver.)
- Page 7 ■ KEY FUNCTIONS (HOLD Ver.) KEYS FUNCTIONS Set the zero point. Input or cancel the weight of tare. Make the weight of commodity stable. This weight is average value. Turn on and off the scale. ■ KEY FUNCTIONS (UNIT Ver.) KEYS FUNCTIONS Set the zero point.
-
Page 8: Operations
OPERATIONS ■Turn on the scale by pressing the key. The display will show all the segments and count up "0" to "9". You may stop this automatic counting by pressing the key. ■ When you turn on the display, make sure that platter is empty. Otherwise, display will show "Err 1", an error of initial zero range. -
Page 9: Changing Unit Of Weight
④ Remove container and ⑤ Press the key, then commodity, then the display display will show the will show the weight of the "0.000". container with "-" symbol. 3. Changing Unit of Weight (FW500, Unit ver. only) ■ Press the key in the simple weighing mode. -
Page 10: How To Set Auto Power Off
5. How to Set the Auto Power Off Auto-Power-off function automatically power off as time limits. This function is helpful to save battery, when not in use. This function is helpful to save battery, when not in use. ① When the scale is turned ②... -
Page 11: Sleep Mode
6. Sleep mode (LED ver.) The battery life can be extended with this function. ① After activating the ② You can browse available ③ Press the ZERO key to automatic power-off feature, values by pressing the TARE select the current value. the scale displays “SUS60”... -
Page 12: Battery Maintenace
The "Err 1" occurs when a current zero point has Please call your "Err 1" shifted from the last span calibration. CAS dealer. Please remove the "Err 3" The "Err 3" is an overload error. weight. 1. Cautions for using Lead-acid battery. -
Page 13: Specifications
SPECIFICATIONS (FW500-C) MODEL FW500-C Max 3/6 kg Max 6/15 kg Max 15/30 kg Approval e=d=1/2 g e=d=2/5 g e=d=5/10 g External 1/3,000 dual 1/3,000 dual 1/3,000 dual Resolution MAX Tare -2.999 kg -5.998 kg -14.995 kg Display 106 x 33 mm 5 digit LCD Symbols STABLE, ZERO, TARE, g, kg, lb, oz, Low Battery Keys... - Page 14 SPECIFICATIONS (FW500-E) MODEL FW500-E Max 3/6 kg Max 6/15 kg Max 15/30 kg Approval e=d=1/2 g e=d=2/5 g e=d=5/10 g External 1/3,000 dual 1/3,000 dual 1/3,000 dual Resolution MAX Tare -2.999 kg -5.998 kg -14.995 kg Display 77 x 20 mm 5 digit LED...
- Page 15 SPECIFICATIONS (FW500-C) MODEL FW500-C 6 lb x 0.002 lb / 15 lb x 0.005 lb / 15 lb x 0.005 lb / 30 lb x 0.01 lb / 30 lb x 0.01 lb / 60 lb x 0.02 lb / CAPACITY 3 000 g x 1 g / 6 000 g x 2 g, 6 000 g x 2 g / 15 000 x 5 g,...
- Page 16 SPECIFICATIONS (FW500-E) MODEL FW500-E 6 lb x 0.002 lb / 15 lb x 0.005 lb, 15 lb x 0.005 lb / 30 lb x 0.01 lb, 30 lb x 0.01 lb / 60 lb x0.02 lb, CAPACITY 3 000 g x 1 g / 6 000 g x 2 g...
- Page 17 MEMO...
