System Architecture
AC or DC power supply
Dual cooling fans
Dual SCSI connectors with Ultra3 SCSI LVD, Ultra2 SCSI LVD, or Ultra SCSI single−ended
interface to host
Disk Tray Key Facts
Each Sun StorEdge S1 array disk tray holds a maximum of three, low profile, 3.5−inch, hot−pluggable
disk modules.
All drives are mounted in a spud bracket for easy installation and removal from the tray.
High performance, 10K rpm, 18 or 36 GB drives.
The drives use SCA−2 connectors in which the ground leads make first contact for hot−pluggable
support. This enables electrical hot plugging. The cable−free drives plug directly into the backplanes to
provide higher reliability.
Storage Subsytem Manager
The Sun StorEdge S1 array comes with Storage Subsystem Manager 2.0, allowing customers to monitor
the Sun StorEdge S1 array from any system in the network running the Solaris™ Operating Environment
for temperature, status, or disk drive information.
Sun StorEdge S1 Array
Just the Facts
Figure 2. Sun StorEdge S1 Array Enclosure
9
9/27/01
