  • Page 1 Rondò Estelle...

  • Page 2: Table Of Contents

    Remove the “Testing Certificate” from inside the combustion chamber (“RONDÒ” version) and keep together with the instructions manual CONTENTS BOILER DESCRIPTION 1. 1 INTRODUCTION ..................24 DIMENSIONAL DETAILS TECHNICAL FEATURES .

  • Page 3: Boiler Description

    BOILER DESCRIPTION 1. 1 INTRODUCTION thermal efficiency for economical per- with combustion hinged door, mat- formance. This manual provides the chable with a separate boiler unit The new “RONDÒ - ESTELLE” series of instructions for the following boiler “BA100 - BA150 - BA200”. cast iron boilers has been designed in models: compliance with the Efficiencies...

  • Page 4: Technical Features

    1.2. 1 D.H.W. storage tank BA BA 100 BA 150 BA 200 BA 100 BA 150 BA 200 D.H.W. outlet 3/4” 3/4” 3/4” ø mm Re-circulation 3/4” 3/4” 3/4” H mm 1175 1265 D.H.W. inlet 3/4” 3/4” 3/4” M2 D.H.W. tank flow 1”...

  • Page 5: Functional Diagram

    FUNCTIONAL DIAGRAM 5 Non-return valve 10 D.H.W. storage tank 1 Burner 6 Automatic air vent 11 D.H.W. tank expansion vessel 2 Boiler 7 D.H.W. pump 12 D.H.W. tank safety valve 3 Boiler thermometer 8 Magnesium anode 13 Hydrometer 4 Boiler drain 9 D.H.W.

  • Page 6: Installation

    INSTALLATION 2. 1 BOILER ROOM 2.3.3 D.H.W. storage tank conform to the following formula: The boiler room should feature all the The “RONDÒ -ESTELLE ” boilers may S = K √H characteristics required by standards be matched with the separate boiler governing liquid fuel heating systems.

  • Page 7: Electrical Connection

    6. Connect the burner with the cable supplied. NOTE: SIME declines all responsibility for injury caused to persons due to failure to earth the boiler. Main switch 2.6. 1 Electrical connection TS Safety stat C.H.
  • Page 8 – remove the casing lid of the boiler the terminal board of the boiler; board of the boiler unit (fig. 7); and the back protection of the con- – remove the protection of the boiler – connect the cables as shown in the trol panel in order to have access to unit to have access to the terminal diagram (fig.

  • Page 9: Use And Maintenance

    USE AND MAINTENANCE 3. 1 COMMISSIONING THE BOILER RONDÒ - ESTELLE When commissioning the boiler always make sure that: – the system has been filled with water and adequately vented; – the flow and return valves are fully open; – the flue and chimney are free from obstructions;...
  • Page 10 RONDO' 3/4 ESTELLE 3/4 RONDO' 5/6 ESTELLE 5/6 Fig. 8 ating conditions has life span of 5 years. It is, however, advisable to check the erosion annually and replace it if worn. To disassemble the tank unit flange (1), remove the cover (5) and unscrew the two nuts that fix the upper cover (4).

  • Page 11: Frost Potection

    – disassemble the right side (10) fol- lowing the same operations. 3.3.4 Fault finding Herefater we outline a number of potential problems that may occur on the appliance and the relevant list of actions required. A working fault, in most cases, provocates the “lock out” signal onto the control panel of the control box.
