Optics
P/N / Model Sensor
GMV-6800-1000G
GMV-6800-1002G
1/3", SXGA (1280 x 960) CCD,
up to 20 FPS, Mono
GMV-6800-1004G
GMV-6800-1006G
GMV-6800-1010G
GMV-6800-1012G
1/3", WVGA (752 x 480) CMOS,
up to 60 FPS, Mono
GMV-6800-1014G
GMV-6800-1016G
1/3", SXGA (1280 x 960) CCD,
GMV-6800-1022G
up to 20 FPS, Color
GMV-6800-1030G
GMV-6800-1032G
2/3", WUXGA (2048 x 1088)
CMOS, up to 48 FPS, Mono
GMV-6800-1034G
GMV-6800-1036G
GMV-6800-1200G
GMV-6800-1202G
1/3", SXGA (1280 x 960) CCD,
up to 20 FPS, Mono
GMV-6800-1204G
GMV-6800-1206G
GMV-6800-1210G
GMV-6800-1212G
1/3", WVGA (752 x 480) CMOS,
up to 60 FPS, Mono
GMV-6800-1214G
GMV-6800-1216G
1/3", SXGA (1280 x 960) CCD,
GMV-6800-1222G
up to 20 FPS, Color
GMV-6800-1300G
GMV-6800-1302G
1/3", SXGA (1280 x 960) CCD,
up to 20 FPS, Mono
GMV-6800-1304G
GMV-6800-1306G
GMV-6800-1310G
GMV-6800-1312G
1/3", WVGA (752 x 480) CMOS,
up to 60 FPS, Mono
GMV-6800-1314G
GMV-6800-1316G
1/3", SXGA (1280 x 960) CCD,
GMV-6800-1322G
up to 20 FPS, Color
GMV-6800-1400G
GMV-6800-1402G
1/3", SXGA (1280 x 960) CCD,
up to 20 FPS, Mono
GMV-6800-1404G
GMV-6800-1406G
GMV-6800-1410G
GMV-6800-1412G
1/3", WVGA (752 x 480) CMOS,
up to 60 FPS, Mono
GMV-6800-1414G
GMV-6800-1416G
1/3", SXGA (1280 x 960) CCD,
GMV-6800-1422G
up to 20 FPS, Color
GMV-6800-1500G
GMV-6800-1502G
1/3", SXGA (1280 x 960) CCD,
up to 20 FPS, Mono
GMV-6800-1504G
GMV-6800-1506G
GMV-6800-1510G
GMV-6800-1512G
1/3", WVGA (752 x 480) CMOS,
up to 60 FPS, Mono
GMV-6800-1514G
GMV-6800-1516G
1/3", SXGA (1280 x 960) CCD,
GMV-6800-1522G
up to 20 FPS, Color
Vision HAWK Smart Camera Guide
Vision HAWK Smart Camera General Specifications
Shutter
6µs to 100ms (1/150,000 to 1/10)
Default = 666µs (1/1,500)
25µs to 100ms (1/40,000 to 1/10)
Default = 400µs (1/2,500)
6µs to 100ms (1/150,000 to 1/10)
Default = 666µs (1/1,500)
25µs to 100ms (1/40,000 to 1/10)
Default = 400µs (1/2,500)
6µs to 100ms (1/150,000 to 1/10)
Default = 666µs (1/1,500)
25µs to 100ms (1/40,000 to 1/10)
Default = 400µs (1/2,500)
6µs to 100ms (1/150,000 to 1/10)
Default = 666µs (1/1,500)
25µs to 100ms (1/40,000 to 1/10)
Default = 400µs (1/2,500)
6µs to 100ms (1/150,000 to 1/10)
Default = 666µs (1/1,500)
25µs to 100ms (1/40,000 to 1/10)
Default = 400µs (1/2,500)
6µs to 100ms (1/150,000 to 1/10)
Default = 666µs (1/1,500)
25µs to 100ms (1/40,000 to 1/10)
Default = 400µs (1/2,500)
6µs to 100ms (1/150,000 to 1/10)
Default = 666µs (1/1,500)
Focal Range
Acquisition
Depends on
lens
Progressive
scan, square
pixel
Progressive
scan, square
pixel
2" (51 mm) to
8" (203 mm)
(liquid lens
autofocus -
standard
Vision HAWK
only)
C-3
C
