CHAPTER 2
This section contains information about system components as well as
information to help you connect the Vision HAWK Smart Camera. Specific
information describes connectors, adapters, cables, pinouts, and signals.
Note: There are no user-serviceable parts inside.

Hardware Components

Table 2-1 lists Vision HAWK Smart Camera hardware components.
TABLE 2–1.
Part Number Description
Demo Kit
98-000215-01 Demo Kit (Power Supply, Camera Stand, Ethernet Host Cable, Carrying Case, Documentation)
Power Supplies
97-000012-01 Power Supply, M12 12-pin Socket, 1.3 m
97-000012-04 Power Supply, M12 12 pin Plug, 1.3m
Communication Devices and Cables
98-000103-01 QX-1 Interface Device
61-000148-02 Cordset, Common, M12 12 Pin, Socket to M12 12 Pin Plug, 3M
61-000162-02 Cordset, Common, M12 12 Pin, Socket to M12 12 Pin Plug, 1M
61-000153-02 Cordset, Host, Serial M12 12 pin Socket to DB9 Socket, 1M
61-000164-02 Cordset, Host, Serial, M12 12 pin Socket to DB9 Socket, 3M
61-000152-02 Cordset, Host, Serial, M12 12 pin Plug to DB9 Socket, 1M
Vision HAWK Smart Camera Guide

System Components

Vision HAWK Smart Camera Hardware Components
2
2-1
