Chapter 3
Optics and Lighting

Vision HAWK Color

This section describes Vision HAWK Smart Camera color functionality, which
is available for the following models:
• GMV-6800-1022G Vision HAWK, SXGA, Color, AV+VS, C-Mount
• GMV-6800-1222G Vision HAWK, SXGA, Color, AV+VS, 30° Lens
• GMV-6800-1322G Vision HAWK, SXGA, Color, AV+VS, 45° Lens
• GMV-6800-1422G Vision HAWK, SXGA, Color, AV+VS, 12° Lens
• GMV-6800-1522G Vision HAWK, SXGA, Color, AV+VS, 15° Lens
The following topics are outlined in this section:
• White balance operation
• White balance factory setup
• White balance calibration
• White balance customer parameter setup
–
3-12
Ability to restore factory default values
Vision HAWK Smart Camera Guide
