Appendix B
Cable Specifications
61-000160-03 Cable, Host, Ethernet, M12 8-pin Plug to RJ45, 1 m
The 61-000160-03 Cable, Host, Ethernet, M12 8-pin Plug to RJ45, 1 m
is a 1 meter cable with an 8-pin M12 connector on one end and a
standard RJ45 connector on the other end.
Figure B-1 shows the 61-000160-03 Cable, Host, Ethernet, M12 8-pin Plug
to RJ45, 1 m.
FIGURE B–1.
M12 8-Pin Plug
Important: Be sure that the retaining clip on the RJ45 connector has
locked into place in the Ethernet receptacle on the PC and is not being
impeded by the rubber housing.
Note: A screw-down version of this cable is also available (61-000160-02).
B-2
Cable, Host, Ethernet, M12 8-pin Plug to RJ45, 1 m
Vision HAWK Smart Camera Guide
RJ45
