Future light MH - 680 Service Manual

Hide thumbs Also See for MH - 680:

Advertisement

Quick Links

Download this manual See also: User Manual
Service manual V 1
MH - 680

Advertisement

loading
Need help?

Need help?

Do you have a question about the MH - 680 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Future light MH - 680

Summary of Contents for Future light MH - 680

  • Page 1 Service manual V 1 MH - 680...
  • Page 2 PCB14 ROTATION OF GOBOS STROBO1 H14L J4L H4L KD1208PTS1-6 KD1208PTS1-6 H10R J41L J42L H11L J11L J43L J10R ROTATING GOBOWHEEL J44L SV1R STROBO2 J3L H3L H16R HAL506 J31L H5RJ5R J32L H10L J10L MAG 5 PCB9 J34L EZ 670 J13L HJ21 ZOOM H6RJ6R PCB3/R EZ 872...
  • Page 3 IN1A OUT1Y IN2A OUT2Y 74HC04 IN3A OUT3Y IN1A OUT4Y IC11 EI1,2 L293D 74HC04 EI3,4 VCC1 VCC2 74HC04 IN1A OUT1Y IN2A OUT2Y 74HC04 IN3A OUT3Y IN1A OUT4Y IC10 EI1,2 L293D EI3,4 RTCC VCC1 MCLR VCC2 OSC1 OSC2/CLKOUT IN1A OUT1Y IN2A OUT2Y PIC16C57C IN3A OUT3Y...
  • Page 4 CON1 PSL10 IC13 DMX IN 100n 220K 220R 220R 220p 220p 220K SN75176 DMX OUT 220p 220p 100n 0.5R 0.5R 220M POWER IN POWER OUT LAMP IN RC0/AD0 RD0/AD8 ARK500/3 RC1/AD1 RD1/AD9 D10 D11 D12 4061.12 IC10 100n RC2/AD2 RD2/AD10 4x1N5819 RC3/AD3 RD3/AD11...
  • Page 5 74HC04 IN1A OUT1Y IN2A OUT2Y 74HC04 IN3A OUT3Y IN1A OUT4Y EI1,2 74HC04 EI3,4 VCC1 VCC2 74HC04 L293D 74HC04 IN1A OUT1Y IN2A OUT2Y IN3A OUT3Y IN1A OUT4Y 74HC04 EI1,2 EI3,4 VCC1 VCC2 L293D RTCC MCLR 74HC04 IN1A OUT1Y OSC1 IN2A OUT2Y OSC2/CLKOUT IN3A OUT3Y...
  • Page 6 KEY501 KEY501 KEY501 KEY501 TEST 24C08 BC807-40 BC807-40 BC807-40 BC807-40 DA56-11EWA DA56-11EWA RC0/AD0 RD0/AD8 RC1/AD1 RD1/AD9 RC2/AD2 RD2/AD10 RC3/AD3 RD3/AD11 RC4/AD4 RD4/AD12 220R RC5/AD5 RD5/AD13 220R RC6/AD6 RD6/AD14 220R RC7/AD7 RD7/AD15 220R 220R RB0/CAP1 RE0/ALE 220R RB1/CAP2 RE1/OE 220R RB2/PWM1 RE2/WR 220R 270R...
  • Page 7 NAME: MH-680 TITLE: COVERS DOCUMENT: 99010240 28.1.2002 1 OF 14 VERSION: DATE: SHEET:...
  • Page 8 34 25 NAME: MH-680 TITLE: ASSEMBLY OF HEAD DOCUMENT: 99010239 28.1.2002 2 OF 14 VERSION: DATE: SHEET:...
  • Page 9 Detail wiew of Yoke Prism: 1 27 16 20 19 21 26 22 27 16 20 21 19 22 26 26 22 15 16 NAME: MH-680 TITLE: MODULE OF PRISM + OBJECT LENS DOCUMENT: 99010239 VERSION: DATE: 28.1.2002 SHEET: 3 OF 14...
  • Page 10 25 28 38 37 23 24 29 27 29 27 5 20 NAME: MH-680 TITLE: MODULE OF ROTATING GOBOS DOCUMENT: 99010239 VERSION: DATE: 28.1.2002 SHEET: 4 OF 14...
  • Page 11 NAME: MH-680 TITLE: WHEEL RG 5+1 DOCUMENT: 99010270 28.1.2002 5 OF 14 VERSION: DATE: SHEET:...
  • Page 12 NAME: MH-680 TITLE: WHEEL ZOOM DOCUMENT: 99010199 28.1.2002 6 OF 14 VERSION: DATE: SHEET:...
  • Page 13 25 1 21 15 21 16 24 19 21 15 18 22 20 21 4 5 13 NAME: MH-680 13 20 8 23 3 TITLE: GOBO - COLOR DOCUMENT: 99010239 28.1.2002 7 OF 14 VERSION: DATE: SHEET:...
  • Page 14 10 12 11 NAME: MH-680 TITLE: WHEEL GOBO - COLOR DOCUMENT: 99010227 28.1.2002 8 OF 14 VERSION: DATE: SHEET:...
  • Page 15 NAME: MH-680 TITLE: WHEEL COLOR 8 DOCUMENT: 99010259 28.1.2002 9 OF 14 VERSION: DATE: SHEET:...
  • Page 16 NAME: MH-680 TITLE: SOURCE OF LIGHT DOCUMENT: 99010239 28.1.2002 10 OF 14 VERSION: DATE: SHEET:...
  • Page 17 25 41 12 26 24 34 58 29 11 57 38 21 52 47 54 48 31 8 27 6 53 36 NAME: MH-680 TITLE: ARM OF HEAD DOCUMENT: 99010222 28.1.2002 11 OF 14 VERSION: DATE: SHEET:...
  • Page 18 19 28 NAME: MH-680 TITLE: AXE "X" DOCUMENT: 99010219 VERSION: DATE: 28.1.2002 SHEET: 12 OF 14...
  • Page 19 47 33 46 5 46 46 23 22 61 45 16 46 57 13 39 9 8 37 43 2 42 53 40 46 60 62 12 53 50 20 15 50 NAME: MH-680 TITLE: BASE - 240V version DOCUMENT: 99010257 VERSION: DATE:...
  • Page 20 45 30 52 59 48 33 47 5 47 47 23 22 47 58 13 39 9 8 37 42 54 40 47 61 54 51 20 15 51 NAME: MH-680 TITLE: BASE - 110V version DOCUMENT: 99010258 VERSION: DATE: 28.1.2002 SHEET: 14 OF 14...
