DVR2
DUAL CAMERA DVR with GPS
SPECIFICATIONS
GENERAL
- Display:
- Image Sensor:
- Resolutions:
- Display Format:
- Picture Format:
- Functions:
- Viewing Angle:
- Camera Adjustment:
- Memory Support:
- GPS Function:
- Google Maps Data:
- G-Sensor:
- Seamless loop recording:
- Auto Record:
- Power Supply:
- Battery:
- Mounting:
INSTRUCTION MANUAL
2.7" LCD TFT
3 Megapixels (Front)
HD 720p (Front), 480p (Rear)
16:9
JPEG
Digital Video Camera/Digital Voice Recorder
140° (Front), 120° (Rear)
Front - 7 Point (Vertical)
1 x 32GB Micro SD Card (Not Included)
Yes
Speed, G-Sensor Data
Yes
Yes
Yes - After Power On
12/24V Cig Lead
Built-in Lithium Battery
Suction Bracket
1
1
INCLUDED
- Suction Bracket
- 12/24V Car Charger
- GPS Antenna
Advertisement
Table of Contents
Related Manuals for Axis DVR2
Summary of Contents for Axis DVR2
- Page 1 DVR2 DUAL CAMERA DVR with GPS SPECIFICATIONS GENERAL INCLUDED - Display: 2.7” LCD TFT - Suction Bracket - Image Sensor: 3 Megapixels (Front) - 12/24V Car Charger - Resolutions: HD 720p (Front), 480p (Rear) - GPS Antenna - Display Format:...
-
Page 2: Table Of Contents
CONTENTS Preface ..................Page 3 Features..................Page 3 1. Product Structure ..............Page 4 2. Beginning to use DVR recorder .......... Page 6 a) Battery Charging b) Insert a memory card c) Adjust the lens position d) Turn on and off 3. -
Page 3: Preface
PREFACE This advanced DVR system has 3 exiciting features: (1) Built-in double lens to simulaneously capture two images at front and back. (2) Newly added GPS module can record the whole driving route. Using specialized software, you can play the video on a computer and at the same time connect to Google Maps. -
Page 4: Product Structure
1. PRODUCT STRUCTURE... -
Page 6: Beginning To Use Dvr Recorder
2. Beginning to use DVR recorder a) Battery Charging There are two methods for battery charging: 1: Using a USB cable (not supplied) to connect the DVR to a computer. 2: Using the vehicle power socket. During charging, using the supplied cigarette power lead, the indicator glows red. When charging is complete, the indicator automatically extinguishes. -
Page 7: Basic Operations
3. Basic Operations a) Change operating mode This machine has two operating modes: Pickup and Playback. Press MODE button to change between them. b) Setup menu Press MENU button to enter MENU page. Now the “Menu setting” is in blue background. Click “OK”... - Page 8 This DVR device does not support USB protocol. Computer access to the a card reader). Notice: (1) For easy use and to avoid software damage, it is recommended that a backup be taken. (2) The computer operating system must be Windows 2000 / XP /Vista / Windows 7, MAC OS x above 10.3.6.
- Page 9 4. Select double lens channel: Clicking the ActiveX can select double lens channel of video playing: double lens / front lens / back lens. After selecting the path, click “save”. 7. Delete document: 8. Kit: Kit can proceed as follows: SD card formatting/uploadsoftware to the SD card / SD card speed test / map selection and user password setting.
- Page 10 9. Google map: Click and the computer will connect to Google Maps via the Internet and show travel path. You can then trace the path of the vehicle. 10. Gravity Sensor: Click to watch the video on the computer and at the same time read and display the gravity sensing data, trace accidents and any abnormal events when driving.
-
Page 11: Reset Unit
5. Reset unit When the unit functions abnormally or freezes, press the reset button and then restart the unit. Now the original factory settings are restored. 6. Product features - Dual Lens: The front lens has an ultra wide angle of 140 degrees can be rotated up and down 20 degrees.
