DVR4
COMPACT FULL HD DVR with GPS
SPECIFICATIONS
GENERAL
- Display:
- Chipset:
- Image Sensor:
- Resolutions:
- Lens Viewing Angle:
- Memory Support:
- GPS Function:
- Google Maps Data:
- G-Sensor:
- Motion Detection:
- Seamless loop recording:
- Auto Record:
- Outputs:
- Still Photography:
- PC Interface:
- Power Supply:
- Battery:
- Dimensions:
- Mounting:
INSTRUCTION MANUAL
1.5" TFT LCD
Ambarella A7
4MP CMOS
1920x1080p, 1440x1080p, 1280x720p 30fps
130°
Up to 32GB Micro SD Card (included)
Yes
Route, Speed, G-Sensor Data
Yes
Yes
Yes
Yes - After Power On
HDMI, AV
Yes
USB
12/24V Cig Lead - 5V Output
Built-in Lithium Battery
72W x 38H x 46Dmm (Without Mount)
2 Sided Tape
INCLUDED
- 12/24V Car Charger
- GPS Antenna Glass Mount
- Mini USB Lead
- 3.5mm AV Lead
- 32GB Micro SD Card
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Axis DVR4
Summary of Contents for Axis DVR4
- Page 1 DVR4 COMPACT FULL HD DVR with GPS SPECIFICATIONS GENERAL INCLUDED - Display: 1.5” TFT LCD - 12/24V Car Charger - Chipset: Ambarella A7 - GPS Antenna Glass Mount - Image Sensor: 4MP CMOS - Mini USB Lead - Resolutions: 1920x1080p, 1440x1080p, 1280x720p 30fps - 3.5mm AV Lead...
- Page 2 PREFACE Thank you for choosing this mobile safety product! change without prior notice. Accessories Included: Name: Quantity (PCS) Black Box Recorder Car Adapter (Input: 12-24V) / (Output: 5V) USB Cable Adhesive Sticker Fixed Windscreen Bracket Mini USB Lead User Manual...
- Page 3 FEATURES • 32GB recording capacity. • 130° ultra wide angle lens. • 1920 x 1080P FULL HD high quality resolution. • 4 mega pixel Camera • 4x digital zoom. Still image 8x zoom. • 1.5 Inch high resolution LCD. • View video during record mode. •...
-
Page 4: Product Structure
PRODUCT STRUCTURE 2. USB port 1: Can connect to the charger and computer by USB. 3. AV port. While recording, press for mute. 5. OK key: Press to start recording. Hold down to take a picture. In Menu, press to ensure selection. While recording, press for SOS. -
Page 5: Light Indicator
DISPLAY 1. ICONS Video Mode Start Recording Camera Mode Take a picture Battery TF Card Motion Detection V:------KM/H Car speed monitor after White Balance GPS locates satellite (Auto) USB connecting Resolution Date & Time display FULL HD/1080P/720P 2014/01/01 01 : 07AM Loop recording time (1 min) 2. - Page 6 3. MENU Press Menu (Hold down UP button) to see the menu below. Choose the desired item by up/down buttons. MAIN MENU 1. Video Resolution: FULL HD, 1080P30, 720P30 2. Photo size: 0.9M, 2M, 3M ,4M 4. ISO: AUTO/100/200/400 5. White Balance: AUTO/Sunny/Incandescent/Fluorescent/Cloudy 6.
-
Page 7: Setting Language
OPERATIONS GUIDE 1. Charging This camcorder can be charged by the car adapter or by connecting to a computer. 2. Connect to the car charger 1. When used as a car camcorder turn on the Loop Recording function. Then connect the camcorder by the car charger. Once the vehicle is switched on, Attention: Please use the supplied car charger to power the DVR. -
Page 8: Take Pictures
8. Take pictures 1. Choose photo size: Long press Menu to see the setup menu. The second item is photo size: 0.9 Mega Pixels/2M/3M/4M. 4M is best but largest. Press to exit. 2. In standby mode, hold down the OK key to take a picture. During video recording, press OK to capture a picture. - Page 9 12. Stamp: 1. After you choose a stamp and start recording, the stamp would be automatically When you play back the video, the stamp can be seen. (picture 1) 2. Driver number is 9 character driver or license plate numbers. Picture 1 Picture 2 13.
-
Page 10: Google Map
Google Map 1. Find the GPS player in the folder and open it. A GPS player with Google map (see picture 2) will display. 2. After you record the video with GPS, connect your machine with computer. Open SD card disk → DCIM → 100MEDIA. PC Camera 1. -
Page 11: Troubleshooting
Troubleshooting Under normal operating conditions, if the product has problems, please refer to the following solutions. • Can’t record a video or take a picture storage space. • Automatically stops while recording with SDHC. High-speed card will be signed with “C6”/”C10”. •... - Page 12 DVR4...
