2. Installation and Operation

There are two different types of online UPS: standard and long-run models. Please refer to the following model table.
E4 LCD 10K TT
E4 LCD 15K TT
E4 LCD 20K TT
E4 LCD 30K TT
We also offer optional parallel functions on request for both types. The UPS with parallel function is called a "Parallel
model". We will give a detailed description of the installation and operation for the Parallel Model in the following
chapter.

2-1. Unpacking and Inspection

Unpack the package and check the package contents. The shipping package contains:
● One UPS
● One user manual
● One monitoring software CD
● One RS-232 cable (option)
● One USB cable
● One EPO plug
● One parallel cable (only available for parallel model)
● One share current cable (only available for parallel model)
NOTE: Before installation, please inspect the unit. Make sure that nothing inside the package was damaged during
transportation. If there are parts missing or the unit is damaged do not turn it on. Notify the carrier and dealer
immediately. Please keep the original packaging in a safe place for future use.
INFOSEC UPS SYSTEM – 4 rue de la Rigotière – 44700 Orvault – France – www.infosec-ups.com
51
Hot Line Tel : +33 (0)2 40 76 15 82 – fax : +33(0)2 40 94 29 51 – hotline@infosec.fr –12 13 AA 59 203 07
Model Type
Standard model
Model
E4 LCD 10K STT
E4 LCD 15K STT
Long-run model
E4 LCD 20K STT
E4 LCD 30K STT
Type
