INFOSEC UPS SYSTEM E4 LCD 10K TT User Manual page 78

Description
Battery mode
LCD display
Description
Bypass mode
LCD display
INFOSEC UPS SYSTEM – 4 rue de la Rigotière – 44700 Orvault – France – www.infosec-ups.com
77
Hot Line Tel : +33 (0)2 40 76 15 82 – fax : +33(0)2 40 94 29 51 – hotline@infosec.fr –12 13 AA 59 203 07
When the input voltage/frequency is beyond the acceptable range or power
failure, UPS will backup power from battery and alarm will beep every 4 seconds..
When input voltage is within acceptable range and bypass is enabled, turn off the
UPS and it will enter Bypass mode. Alarm beeps every two minutes
