Netopia R910 User Reference Manual page 95

Profile Name:
Profile Enabled:
Data Link Encapsulation...
Data Link Options...
IP Enabled:
IP Profile Parameters...
COMMIT
When you define a Connection Profile as using ATMP by selecting ATMP as the datalink encapsulation method,
and then select Data Link Options, the ATMP Tunnel Options screen appears.
ATMP Partner IP Address:
Tunnel Via Gateway:
Network Name:
Password:
Data Encryption...
Key String:
Initiate Connections:
On Demand:
Idle Timeout (seconds):
Enter an IP address in decimal and dot form (xxx.xxx.xxx.xxx).
In this Screen you will configure the GRE/ATMP specific connection params.
Note: An ATMP tunnel cannot be assigned a dynamic IP address by the remote server, as in a PPP connection.
When you define an ATMP tunnel profile, the Local WAN IP Address, assigned in the IP Profile Parameters
screen, must be the true IP address, not 0.0.0.0, if NAT is enabled.
Note: Profiles using ATMP do not offer a Telco Options screen.
ATMP Partner IP Address specifies the address of the other end of the tunnel. When unspecified, the
I
gateway can not initiate tunnels (i.e., act as a foreign agent) for this profile; it can only accept tunnel
requests as a home agent.
Add Connection Profile
Profile 1
+-------------+
+-------------+
| PPP
| Frame Relay |
| ATM FUNI
| ATMP
| PPTP
+-------------+
CANCEL
ATMP Tunnel Options
173.167.8.134
0.0.0.0
sam.net
****
DES
Yes
Yes
300
Virtual Private Networks (VPN) 10-95
|
|
|
|
