The Add Connection Profile screen appears.
Profile Name:
Profile Enabled:
Data Link Encapsulation...
IP Enabled:
IP Profile Parameters...
Interface Group...
COMMIT
I
From the Data Link Encapsulation pop-up menu select IPsec.
I
Then select Data Link Options. The IPsec Encryption & Authentication Options screen appears.
Encryption Transform...
Encryption Key:
Authentication Type...
Authentication Transform...
Authentication Key:
Compression Type...
The screen offers the following Data Link Options for an IPsec Connection Profile.
I
You must specify an Encryption Transform. The choices are DES or NULL. The default is DES.
Add Connection Profile
IPsec Encryption & Authentication Options
********************************
COMMIT
Virtual Private Networks (VPN) 10-81
Profile 1
+-------------+
+-------------+
| PPP
|
| RFC1483
|
| ATMP
|
| PPTP
|
| IPsec
|
+-------------+
Primary
CANCEL
+----------------+
+----------------+
| DES
|
| NULL
|****
|
|
+----------------+
ESP
HMAC-MD5-96
None
CANCEL
