Netopia R910 User Reference Manual page 105

The Netopia R910 Router supports the Point-to-Point protocol over Ethernet (PPPoE) for use of PPP to connect
through a DSL or cable modem. Some ISPs require user name and password authentication to connect you with
their DSL or cable service. PPPoE allows user name and password authentication to the ISP via your R910's
Ethernet interface to your DSL or cable modem.
To configure PPP authentication in your R910, you first enable PPP over Ethernet and then create a Connection
Profile for your Internet connection.
From the Main Menu select WAN Configuration, WAN Setup, and then EN (Wan Module 1) Setup. Press
Return.
Main
Menu
The WAN Ethernet Configuration screen appears.
Address Translation Enabled:
Local WAN IP Address:
NAT Map List...
NAT Server List...
Filter Set...
Remove Filter Set
Receive RIP:
Enable PPP over Ethernet:
Wan Ethernet MAC Address:
Toggle Enable PPP over Ethernet to On, using the Tab key. Press Return, and then Escape twice to return to
WAN Configuration. Select Add Connection Profile. Press Return.
The Add Connection Profile screen appears.
WAN Configuration
WAN Ethernet Configuration
WAN EN (WAN Module 1)
Setup
Yes
0.0.0.0
Easy-PAT List
Easy-Servers
Both
On
00:00:c5:70:03:4a
PPP over Ethernet 11-105
Setup
