12-118 User's Reference Guide

SNMP

The Netopia R910 includes a Simple Network Management Protocol (SNMP) agent, allowing monitoring and
configuration by a standard SNMP manager.
The Netopia R910 supports the following management information base (MIB) documents:
I MIB II (RFC 1213)
I Interface MIB (RFC 1229)
Ethernet MIB (RFC 1643)
I
Netopia MIB
I
These MIBs are on the Netopia R910 CD included with the Netopia R910. Load these MIBs into your SNMP
management software in the order they are listed here. Follow the instructions included with your SNMP
manager on how to load MIBs.

The SNMP Setup screen

From the Main Menu, select SNMP in the System Configuration screen and press Return. The SNMP Setup
screen appears.
System Name:
System Location:
System Contact:
Read-Only Community String:
Read/Write Community String:
Authentication Traps Enable:
IP Trap Receivers...
Configure optional SNMP parameters from here.
Follow these steps to configure the first three items in the screen:
1. Select System Name and enter a descriptive name for the Netopia R910's SNMP agent.
Main
Configuration
Menu
System
SNMP Setup
public
private
Off
SNMP
