AFL-057A-Z510/Z530 Panel PC
IEI Technology Corp.
MODEL:
AFL-057A-Z510/Z530
5.7" PoE Panel PC with Touch Screen,
Intel® Atom™ Z510/Z530 CPU, Gigabit Ethernet, USB,
RS-232/422/485, RoHS Compliant, IP 64 Protection
Rev. 1.02 – 8 November, 2012
User Manual
Page i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AFL-057A-Z510 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IEI Technology AFL-057A-Z510

Summary of Contents for IEI Technology AFL-057A-Z510

  • Page 1 AFL-057A-Z510/Z530 Panel PC IEI Technology Corp. MODEL: AFL-057A-Z510/Z530 5.7” PoE Panel PC with Touch Screen, Intel® Atom™ Z510/Z530 CPU, Gigabit Ethernet, USB, RS-232/422/485, RoHS Compliant, IP 64 Protection User Manual Page i Rev. 1.02 – 8 November, 2012...
  • Page 2 AFL-057A-Z510/Z530 Panel PC Revision Date Version Changes 8 November, 2012 1.02 Modified Table 3-3: COM1 Mode Settings (SW3) 14 September, 2011 1.01 Added a note on page 32 regarding the pinouts of the 5 V DC input terminal block for the R10 model.
  • Page 3 AFL-057A-Z510/Z530 Panel PC Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.

  • Page 4: Table Of Contents

    AFL-057A-Z510/Z530 Panel PC Table of Contents 1 INTRODUCTION......................1 1.1 O ........................2 VERVIEW 1.1.1 Model Variations ....................2 1.1.2 Standard Features ....................3 1.2 E ....................3 XTERNAL VERVIEW 1.2.1 General Description................... 3 1.2.2 Front Panel ......................4 1.2.3 Rear Panel ......................4 1.2.4 Top Panel and Side Panels.................
  • Page 5 AFL-057A-Z510/Z530 Panel PC 3.6 B ................. 25 OTTOM ANEL ONNECTORS 3.6.1 LAN Connection (PoE Supported)..............25 3.6.1.1 GbE LAN Connector Pinouts ..............26 3.6.2 Serial Device Connection ................27 3.6.3 USB Device Connection................... 28 3.7 P ................... 29 OWER ROCEDURE 3.7.1 Installation Checklist ..................
  • Page 6 AFL-057A-Z510/Z530 Panel PC 5.7 C ........................59 HIPSET 5.7.1 Northbridge Configuration ................60 5.7.2 Southbridge Configuration ................62 5.8 E ......................... 63 A SAFETY PRECAUTIONS ..................65 A.1 S .................... 66 AFETY RECAUTIONS A.1.1 General Safety Precautions ................66 A.1.2 Anti-static Precautions ..................67 A.1.3 Product Disposal .....................
  • Page 7 AFL-057A-Z510/Z530 Panel PC E WATCHDOG TIMER....................105 F HAZARDOUS MATERIALS DISCLOSURE............108 F.1 H IPB P AZARDOUS ATERIALS ISCLOSURE ABLE FOR RODUCTS ERTIFIED AS HS C 2002/95/EC W ........109 OMPLIANT NDER ITHOUT ERCURY Page vii...
  • Page 8 Figure 1-2: Front View ........................4 Figure 1-3: Rear View ........................4 Figure 1-4: Top View........................5 Figure 1-5: Side View........................5 Figure 1-6: AFL-057A-Z510/Z530 Bottom View ................6 Figure 1-7: Dimensions (units in mm) ..................8 Figure 3-1: Back Cover Retention Screws .................16 Figure 3-2: CF Card Location ......................16 Figure 3-3: COM1 RS-232/422/485 Serial Port Select Switch Locations .........18...
  • Page 9 AFL-057A-Z510/Z530 Panel PC Figure C-3: Recovery Tool Setup Menu ..................79 Figure C-4: Command Mode......................79 Figure C-5: Partition Creation Commands.................80 Figure C-6: Launching the Recovery Tool .................82 Figure C-7: System Configuration for Windows ...............82 Figure C-8: Build-up Recovery Partition ..................83 Figure C-9: Press any key to continue ..................83 Figure C-10: Press F3 to Boot into Recovery Mode..............84...
  • Page 10 AFL-057A-Z510/Z530 Panel PC List of Tables Table 1-1: Model Variations ......................2 Table 1-2: AFL-057A-Z510/Z530 System Specifications .............7 Table 3-1: COM1 Mode Settings (SW1+SW4)................17 Table 3-2: COM1 Mode Settings (SW2)..................17 Table 3-3: COM1 Mode Settings (SW3)..................18 Table 3-4: RS-422 Pinouts ......................19 Table 3-5: RS-485 Pinouts ......................19...
  • Page 11 AFL-057A-Z510/Z530 Panel PC BIOS Menus BIOS Menu 1: Main ........................42 BIOS Menu 2: Advanced ......................44 BIOS Menu 3: CPU Configuration ....................44 BIOS Menu 4: IDE Configuration....................45 BIOS Menu 5: IDE Master and IDE Slave Configuration ............46 BIOS Menu 6: Super IO Configuration..................50 BIOS Menu 7: Remote Access Configuration................51...

  • Page 12: Introduction

    AFL-057A-Z510/Z530 Panel PC Chapter Introduction Page 1...

  • Page 13: Overview

    AFL-057A-Z510/Z530 Panel PC 1.1 Overview Figure 1-1: AFL-057A-Z510/Z530 The AFL-057A-Z510/Z530 flat panel PC is a flexible, multi-functional and fanless flat panel PC that can be applied in diverse operational environments and implemented in multi-faceted applications. The AFL-057A-Z510/Z530 comes fully kitted with a high-performance motherboard and a host of other peripheral interface connectors.

  • Page 14: Standard Features

    1.2 External Overview 1.2.1 General Description The AFL-057A-Z510/Z530 is a stylish flat panel PC that comprises of a screen, rear panel, top panel, bottom panel and two side panels (left and right). An ABS/PC plastic front frame surrounds the front screen. The rear panel provides screw holes for a wall-mounting bracket compliant with VESA FDMI standard.

  • Page 15: Front Panel

    AFL-057A-Z510/Z530 Panel PC 1.2.2 Front Panel The front side of the AFL-057A-Z510/Z530 is a flat panel TFT LCD screen surrounded by an ABS/PC plastic frame. Figure 1-2: Front View 1.2.3 Rear Panel The rear panel provides access to retention screw holes that support the wall mounting.

  • Page 16: Top Panel And Side Panels

    AFL-057A-Z510/Z530 Panel PC 1.2.4 Top Panel and Side Panels The top panel and side panels of AFL-057A-Z510/Z530 provides access to slots that support panel mount and rack mount (Figure 1-4 and Figure 1-5). Figure 1-4: Top View Figure 1-5: Side View 1.2.5 Bottom Panel...

  • Page 17: Internal Overview

    TFT LCD screen. Below the metal sheet is a circuit board that is connected to the LCD panel with LED backlight. 1.4 Specifications The technical specifications for the AFL-057A-Z510/Z530 systems are listed in Table 1-2. SPECIFICATION AFL-057A-Z510 AFL-057A-Z530 1.1 GHz Intel®...

  • Page 18: Table 1-2: Afl-057A-Z510/Z530 System Specifications

    10G Acceleration, peak to peak (11ms) Dimension (W x H x D) 180 mm x 135 mm x 55 mm Net/Gross Weight 0.8 Kg Front Panel Protection IP 64 compliant Safety/EMC CE, FCC, CB and CCC Table 1-2: AFL-057A-Z510/Z530 System Specifications Page 7...

  • Page 19: Dimensions

    AFL-057A-Z510/Z530 Panel PC 1.5 Dimensions The dimensions of the AFL-056A-LX and AFL-057-LX flat panel PC are shown in Figure 1-7 below. Figure 1-7: Dimensions (units in mm) Page 8...

  • Page 20: Packing List

    AFL-057A-Z510/Z530 Panel PC Chapter Packing List Page 9...

  • Page 21: Anti-Static Precautions

    Only handle the edges of the PCB: Don't touch the surface of the motherboard. Hold the motherboard by the edges when handling. 2.2 Unpacking Precautions When the AFL-057A-Z510/Z530 is unpacked, please do the following: Follow the antistatic guidelines above. Make sure the packing box is facing upwards when opening.

  • Page 22: Packing List

    If any of the components listed in the checklist below are missing, do not proceed with the installation. Contact the IEI reseller or vendor the AFL-057A-Z510/Z530 was purchased from or contact an IEI sales representative directly by sending an email to ales@iei.com.tw.
  • Page 23 AFL-057A-Z510/Z530 Panel PC The following table lists the optional items that can be purchased separately. Optional Power adapter (25 W, 90 V ~264 V AC, 50/60Hz) (P/N: 63000-FSP025DGAA1705-RS) Panel mount kit (P/N: ALFPK-12) VESA 75 wall mount kit (P/N: AFLWK-12)
  • Page 24 AFL-057A-Z510/Z530 Panel PC USB hybrid card reader (P/N: AFLP-08AMSI-U) Industrial 6-port Lite-Managed P.O.E. Ethernet Switch with 6 x 10/100TX (P/N: IPS-2042TX) 1 GB CompactFlash® card with Windows CE 6.0 pre-installed 1 GB CompactFlash® card with Windows XPE pre-installed 2 GB CompactFlash® card with Windows 7...

  • Page 25: Installation

    AFL-057A-Z510/Z530 Panel PC Chapter Installation Page 14...

  • Page 26: Installation Precautions

    Step 0: 3.3 CF Card Installation The AFL-057A-Z510/Z530 has one CF Type II slot inside the rear panel. To install the CF card, follow the instructions below. Remove the nine retention screws (Figure 3-1) and lift the cover off the flat Step 1: panel PC.

  • Page 27: Figure 3-1: Back Cover Retention Screws

    AFL-057A-Z510/Z530 Panel PC Figure 3-1: Back Cover Retention Screws Lift the cover off and pull down the cover a bit to make it possible to lift the cover Step 2: further more after removing the nine retention screws. Push the power switch while lifting the back cover.

  • Page 28: Jumper Settings

    AFL-057A-Z510/Z530. Before AFL-057A-Z510/Z530 is installed, the jumpers must be set in accordance with the desired configuration. The settings are listed below. 3.4.1 Access the Switches To access the DIP switches, remove the back cover. To remove the back cover, please refer to Section 3.3...

  • Page 29: Figure 3-3: Com1 Rs-232/422/485 Serial Port Select Switch Locations

    AFL-057A-Z510/Z530 Panel PC RS-232 Default RS-422 RS-485 Table 3-3: COM1 Mode Settings (SW3) The COM1 RS-232/422/485 Serial Port Select Switch locations are shown in Figure 3-3 below. Figure 3-3: COM1 RS-232/422/485 Serial Port Select Switch Locations Page 18...

  • Page 30: Com1 Rs-422 And Rs-485 Pinouts

    PC does not fall down and get damaged. The three methods of mounting the AFL-057A-Z510/Z530 are listed below. Wall mounting...

  • Page 31: Wall Mounting

    AFL-057A-Z510/Z530 Panel PC 3.5.1 Wall Mounting To mount the flat panel PC onto the wall, please follow the steps below. Select the location on the wall for the wall-mounting bracket. Step 1: Carefully mark the locations of the four brackets screw holes on the wall.

  • Page 32: Figure 3-5: Chassis Support Screws

    AFL-057A-Z510/Z530 Panel PC Carefully insert the screws through the holes and gently pull the monitor Step 8: downwards until the monitor rests securely in the slotted holes (Figure 3-5). Ensure that all four of the mounting screws fit snuggly into their respective slotted holes.

  • Page 33: Panel Mounting

    AFL-057A-Z510/Z530 Panel PC Figure 3-6: Secure the Panel PC 3.5.2 Panel Mounting To mount the AFL-057A-Z510/Z530 flat panel PC into a panel, please follow the steps below. Select the position on the panel to mount the flat panel PC. Step 1:...

  • Page 34: Figure 3-7: Panel Opening

    Insert the panel mounting clamps into the pre-formed holes along the edges of Step 4: the chassis, behind the aluminum frame. There are a total of 4 panel mounting clamps on the AFL-057A-Z510/Z530. Tighten the screws that pass through the panel mounting clamps until the plastic Step 5: caps at the front of all the screws are firmly secured to the panel (Figure 3-8).

  • Page 35: Arm/Stand Mounting

    Figure 3-8: Tighten the Panel Mounting Clamp Screws 3.5.3 Arm/Stand Mounting The AFL-057A-Z510/Z530 is VESA (Video Electronics Standards Association) compliant and can be mounted on an arm with a 75mm interface pad. To mount the AFL-057A-Z510/Z530 on an arm, please follow the steps below.

  • Page 36: Bottom Panel Connectors

    There is one external RJ-45 LAN connector. The RJ-45 connector enables connection to an external network and provides power to the system. To connect a LAN cable with an RJ-45 connector, please follow the instructions below. Locate the RJ-45 connector on the bottom panel of the AFL-057A-Z510/Z530. Step 1: Page 25...

  • Page 37: Gbe Lan Connector Pinouts

    AFL-057A-Z510/Z530 Panel PC Align the connector. Align the RJ-45 connector on the LAN cable with the Step 2: RJ-45 connector on the bottom panel of the AFL-057A-Z510/Z530. See Figure 3-10. Figure 3-10: LAN Connection Insert the LAN cable RJ-45 connector. Once aligned, gently insert the LAN Step 3: cable RJ-45 connector into the onboard RJ-45 connector.

  • Page 38: Serial Device Connection

    MDI3+ Table 3-6: Ethernet Connector Pinouts 3.6.2 Serial Device Connection The AFL-057A-Z510/Z530 has a single female DB-9 connector on the external peripheral interface panel for a serial device. Follow the steps below to connect a serial device to the AFL-057A-Z510/Z530.

  • Page 39: Usb Device Connection

    AFL-057A-Z510/Z530 Panel PC Secure the connector. Secure the serial device connector to the external Step 3: interface by tightening the two retention screws on either side of the connector. 3.6.3 USB Device Connection There is one external USB 2.0 connector. To connect a USB 2.0 or USB 1.1 device, please follow the instructions below.

  • Page 40: Power -O N Procedure

    WARNING: The AFL-057A-Z510/Z530 includes a 5 V DC power input connector and a RJ-45 connector for PoE power. The user must choose either one to power-up the system. DO NOT use the 5 V DC power and PoE at the same time.

  • Page 41: Figure 3-13: Rj-45 Connector With Poe Support

    IPS-2042TX Ethernet switch which can be purchased from IEI. Figure 3-14: IPS-2042TX Ethernet Switch Connect the PoE-enabled networking device to the power outlet. Step 3: The power LED on the front panel of the AFL-057A-Z510/Z530 will turn to green. Step 4: Page 30...

  • Page 42: Power-On Procedure (Optional Power Adapter)

    Connect the optional power adapter to the power connector of the Step 1: AFL-057A-Z510/Z530. Figure 3-16: Power Connector Connect the power adapter to the power outlet. Step 2: The power LED on the front panel of the AFL-057A-Z510/Z530 will turn to green. Step 3: Step 0: Page 31...

  • Page 43: Software Installation

    AFL-057A-Z510/Z530. 3.8 Software Installation All the drivers for the AFL-057A-Z510/Z530 are on the CD that came with the system. To install the drivers, please follow the steps below. Insert the CD into a CD drive connected to the system.

  • Page 44: Figure 3-18: Introduction Screen

    AFL-057A-Z510/Z530 Panel PC NOTE: If the installation program doesn't start automatically: Click "Start->My Computer->CD Drive->autorun.exe" The driver main menu appears (Figure 3-18). Step 2: Figure 3-18: Introduction Screen Click AFL-057A-Z530/Z510. Step 3: A new screen with a list of available drivers appears (Figure 3-19).

  • Page 45: Figure 3-19: Available Drivers

    AFL-057A-Z510/Z530 Panel PC Figure 3-19: Available Drivers Install all of the necessary drivers in this menu. Step 5: Page 34...

  • Page 46: System Maintenance

    AFL-057A-Z510/Z530 Panel PC Chapter System Maintenance Page 35...

  • Page 47: System Maintenance Introduction

    AFL-057A-Z510/Z530 Panel PC 4.1 System Maintenance Introduction If the components of the AFL-057A-Z510/Z530 fail they must be replaced, please contact the system reseller or vendor to purchase the replacement parts. Back cover removal instructions for the AFL-057A-Z510/Z530 are described below.

  • Page 48: Figure 4-1: Motherboard Retention Screws

    Figure 4-1: Motherboard Retention Screws Push the external interface connector apart from the aluminum cover and lift the Step 3: aluminum cover off the AFL-057A-Z510/Z530. Locate the DDR2 memory module on the motherboard of the flat panel PC Step 4: Remove the DDR memory module by pulling both the spring retainer clips outward from the socket.

  • Page 49: Figure 4-2: Ddr2 So-Dimm Module Installation

    AFL-057A-Z510/Z530 Panel PC Figure 4-2: DDR2 SO-DIMM Module Installation Page 38...

  • Page 50: Bios

    AFL-057A-Z510/Z530 Panel PC Chapter BIOS Page 39...

  • Page 51: Introduction

    AFL-057A-Z510/Z530 Panel PC 5.1 Introduction The BIOS is programmed onto the BIOS chip. The BIOS setup program allows changes to certain system settings. This chapter outlines the options that can be changed. 5.1.1 Starting Setup The AMI BIOS is activated when the computer is turned on. The setup program can be activated in one of two ways.

  • Page 52: Getting Help

    AFL-057A-Z510/Z530 Panel PC Function F2 /F3 key Change color from total three colors. F2 to select color forward. F10 key Save all the CMOS changes, only for Main Menu Table 5-1: BIOS Navigation Keys 5.1.3 Getting Help When F1 is pressed a small help window describing the appropriate keys to use and the possible selections for the highlighted item appears.

  • Page 53: Main

    AFL-057A-Z510/Z530 Panel PC 5.2 Main The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered. The Main menu gives an overview of the basic system information. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset...

  • Page 54: Advanced

    AFL-057A-Z510/Z530 Panel PC System Memory: Displays the auto-detected system memory. Size: Lists memory size The System Overview field also has two user configurable fields: System Time [xx:xx:xx] Use the System Time option to set the system time. Manually enter the hours, minutes and seconds.

  • Page 55: Cpu Configuration

    AFL-057A-Z510/Z530 Panel PC BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit Advanced Settings Configure CPU ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ WARNING: Setting wrong values in below sections may cause system to malfunction > CPU Configuration > IDE Configuration > SuperIO Configuration Select Screen >...

  • Page 56: Ide Configuration

    AFL-057A-Z510/Z530 Panel PC Brand String: Lists the brand name of the CPU being used Frequency: Lists the CPU processing speed FSB Speed: Lists the FSB speed Cache L1: Lists the CPU L1 cache size Cache L2: Lists the CPU L2 cache size 5.3.2 IDE Configuration...

  • Page 57: Ide Master, Ide Slave

    AFL-057A-Z510/Z530 Panel PC IDE Master and IDE Slave When entering setup, BIOS auto detects the presence of IDE devices. BIOS displays the status of the auto detected IDE devices. The following IDE devices are detected and are shown in the IDE Configuration menu:...
  • Page 58 AFL-057A-Z510/Z530 Panel PC LBA Mode: Indicates whether the LBA (Logical Block Addressing) is a method of addressing data on a disk drive is supported or not. Block Mode: Block mode boosts IDE drive performance by increasing the amount of data transferred. Only 512 bytes of data can be transferred per interrupt if block mode is not used.
  • Page 59 AFL-057A-Z510/Z530 Panel PC LBA/Large Mode [Auto] Use the LBA/Large Mode option to disable or enable BIOS to auto detects LBA (Logical Block Addressing). LBA is a method of addressing data on a disk drive. In LBA mode, the maximum drive capacity is 137 GB.
  • Page 60 AFL-057A-Z510/Z530 Panel PC PIO mode 3 selected with a maximum transfer rate of 11.1 MB/s PIO mode 4 selected with a maximum transfer rate of 16.6 MB/s (This setting generally works with all hard disk drives manufactured after 1999. For other disk drives, such as IDE CD-ROM drives, check the specifications of the drive.)

  • Page 61: Super Io Configuration

    AFL-057A-Z510/Z530 Panel PC 5.3.3 Super IO Configuration Use the Super IO Configuration menu (BIOS Menu 6) to set or change the configurations for the FDD controllers, parallel ports and serial ports. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset...

  • Page 62: Remote Access Configuration

    AFL-057A-Z510/Z530 Panel PC Select RS232 or RS485/RS422 [RS/232] Use the Select RS232 or RS485/RS422 option to select the Serial Port 1 signaling mode. Serial Port 1 signaling mode is RS-232 RS232 EFAULT Serial Port 1 signaling mode is RS-422/485 RS422/485...

  • Page 63: Usb Configuration

    AFL-057A-Z510/Z530 Panel PC 5.3.5 USB Configuration Use the USB Configuration menu (BIOS Menu 8) to read USB configuration information and configure the USB settings. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit USB Configuration Enables USB host ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯...

  • Page 64: Pci/Pnp

    AFL-057A-Z510/Z530 Panel PC USB 2.0 Controller [Enabled] Use the USB 2.0 Controller BIOS option to enable or disable the USB 2.0 controller USB 2.0 controller disabled Disabled USB 2.0 controller enabled Enabled EFAULT Legacy USB Support [Enabled] Use the Legacy USB Support BIOS option to enable USB mouse and USB keyboard support.

  • Page 65: Bios Menu 9: Pci/Pnp Configuration

    AFL-057A-Z510/Z530 Panel PC WARNING! Setting wrong values for the BIOS selections in the PCIPnP BIOS menu may cause the system to malfunction. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit Advanced PCI/PnP Settings Available: Specified IRQ ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ is available to be use...
  • Page 66 AFL-057A-Z510/Z530 Panel PC IRQ4 IRQ5 IRQ7 IRQ9 IRQ10 IRQ 11 IRQ 14 IRQ 15 Reserved Memory Size [Disabled] Use the Reserved Memory Size BIOS option to specify the amount of memory that should be reserved for legacy ISA devices. No memory block reserved for legacy ISA devices...

  • Page 67: Boot

    AFL-057A-Z510/Z530 Panel PC 5.5 Boot Use the Boot menu (BIOS Menu 10) to configure system boot options. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit Boot Settings Configure settings ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ during system boot. > Boot Settings Configuration Select Screen ↑...
  • Page 68 AFL-057A-Z510/Z530 Panel PC Quick Boot [Enabled] Use the Quick Boot BIOS option to make the computer speed up the boot process. No POST procedures are skipped Disabled Some POST procedures are skipped to decrease Enabled EFAULT the system boot time Quiet Boot [Enabled] Use the Quiet Boot BIOS option to select the screen display when the system boots.

  • Page 69: Security

    AFL-057A-Z510/Z530 Panel PC Allows the Number Lock on the keyboard to be enabled EFAULT automatically when the computer system boots up. This allows the immediate use of the 10-key numeric keypad located on the right side of the keyboard. To confirm this, the Number Lock LED light on the keyboard is lit.

  • Page 70: Chipset

    AFL-057A-Z510/Z530 Panel PC Change Supervisor Password Use the Change Supervisor Password to set or change a supervisor password. The default for this option is Not Installed. If a supervisor password must be installed, select this field and enter the password. After the password has been added, Install appears next to Change Supervisor Password.

  • Page 71: Northbridge Configuration

    AFL-057A-Z510/Z530 Panel PC BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit Advanced Chipset Settings ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ WARNING: Setting wrong values in below section may cause system to malfunction. > North Bridge Configuration > South Bridge Configuration Select Screen ↑ ↓...
  • Page 72 AFL-057A-Z510/Z530 Panel PC Integrated Graphics Mode Select [Enable, 4 MB] Use the Internal Graphic Mode Select option to specify the amount of system memory that can be used by the Internal graphics device. Disable 1 MB of memory used by internal graphics device...

  • Page 73: Southbridge Configuration

    AFL-057A-Z510/Z530 Panel PC 1360x768 24bit Vesa 1360x768 18bit 1360x768 24bit 5.7.2 Southbridge Configuration Use the Southbridge Configuration menu (BIOS Menu 15) to configure the Southbridge chipset. BIOS SETUP UTILITY Main Advanced PCIPNP Boot Security Chipset Exit Southbridge Configuration ⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯ Audio Controller Codec...

  • Page 74: Exit

    AFL-057A-Z510/Z530 Panel PC EMI. This benefit may in some cases be outweighed by problems with timing-critical devices, such as a clock-sensitive SCSI device. EMI not reduced Disabled EFAULT EMI reduced Enabled 5.8 Exit Use the Exit menu (BIOS Menu 16) to load default BIOS values, optimal failsafe values and to save configuration changes.
  • Page 75 AFL-057A-Z510/Z530 Panel PC Discard Changes Use the Discard Changes option to discard the changes and remain in the BIOS configuration setup program. Load Optimal Defaults Use the Load Optimal Defaults option to load the optimal default values for each of the parameters on the Setup menus.

  • Page 76: A Safety Precautions

    AFL-057A-Z510/Z530 Panel PC Appendix Safety Precautions Page 65...

  • Page 77: Safety Precautions

    DO NOT strike or exert excessive force onto the LCD panel. DO NOT touch any of the LCD panels with a sharp object DO NOT use the AFL-057A-Z510/Z530 in a site where the ambient temperature exceeds the rated temperature Page 66...

  • Page 78: Anti-Static Precautions

    AFL-057A-Z510/Z530 and sever injury to the user. Electrostatic discharge (ESD) can cause serious damage to electronic components, including the AFL-057A-Z510/Z530. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the AFL-057A-Z510/Z530 is opened and any of the electrical components are handled, the following anti-static precautions are strictly adhered to.

  • Page 79: Product Disposal

    Please follow the national guidelines for electrical and electronic product disposal. A.2 Maintenance and Cleaning Precautions When maintaining or cleaning the AFL-057A-Z510/Z530, please follow the guidelines below. A.2.1 Maintenance and Cleaning Prior to cleaning any part or component of the AFL-057A-Z510/Z530, please read the details below. Page 68...

  • Page 80: Cleaning Tools

    AFL-057A-Z510/Z530. A.2.2 Cleaning Tools Some components in the AFL-057A-Z510/Z530 may only be cleaned using a product specifically designed for the purpose. In such case, the product will be explicitly mentioned in the cleaning tips. Below is a list of items to use when cleaning the AFL-057A-Z510/Z530.

  • Page 81: Bbios Options

    AFL-057A-Z510/Z530 Panel PC Appendix BIOS Options Page 70...
  • Page 82 AFL-057A-Z510/Z530 Panel PC Below is a list of BIOS configuration options in the BIOS chapter. 　 System Overview .........................42 　 System Time [xx:xx:xx] .......................43 　 System Date [xx/xx/xx] ......................43 　 ATA/IDE Configurations [Enabled] ..................45 　 IDE Master and IDE Slave....................46 　...
  • Page 83 AFL-057A-Z510/Z530 Panel PC 　 Boot Display Device [Auto]....................61 　 Flat Panel Type [640x480 (generic)]...................61 　 Audio Controller Codec [Enabled] ..................62 　 Spread Spectrum [Disabled]....................62 　 Save Changes and Exit .......................63 　 Discard Changes and Exit....................63 　 Discard Changes........................64 　 Load Optimal Defaults......................64 　...

  • Page 84: C One Key Recovery

    AFL-057A-Z510/Z530 Panel PC Appendix One Key Recovery Page 73...

  • Page 85: One Key Recovery Introduction

    AFL-057A-Z510/Z530 Panel PC C.1 One Key Recovery Introduction The IEI one key recovery is an easy-to-use front end for the Norton Ghost system backup and recovery tool. The one key recovery provides quick and easy shortcuts for creating a backup and reverting to that backup or for reverting to the factory default settings.

  • Page 86: System Requirement

    AFL-057A-Z510/Z530 Panel PC C.1.1 System Requirement NOTE: The recovery CD can only be used with IEI products. The software will fail to run and a warning message will appear when used on non-IEI hardware. To create the system backup, the main storage device must be split into two partitions (three partitions for Linux).

  • Page 87: Supported Operating System

    AFL-057A-Z510/Z530 Panel PC NOTE: Specialized tools are required to change the partition size if the operating system is already installed. C.1.2 Supported Operating System The recovery CD is compatible with both Microsoft Windows and Linux operating system (OS). The supported OS versions are listed below.

  • Page 88: Setup Procedure For Windows

    AFL-057A-Z510/Z530 Panel PC NOTE: Installing unsupported OS versions may cause the recovery tool to fail. C.2 Setup Procedure for Windows Prior to using the recovery tool to backup or restore Windows system, a few setup procedures are required. Hardware and BIOS setup (see Section Step 1: C .2.1)

  • Page 89: Create Partitions

    AFL-057A-Z510/Z530 Panel PC Turn on the system. Step 4: Press the <DELETE> key as soon as the system is turned on to enter the BIOS. Step 5: Select the connected optical disk drive as the 1 boot device. (Boot Step 6:...

  • Page 90: Figure C-3: Recovery Tool Setup Menu

    AFL-057A-Z510/Z530 Panel PC The recovery tool setup menu is shown as below. Step 3: Figure C-3: Recovery Tool Setup Menu Press <5> then <Enter>. Step 4: Figure C-4: Command Mode The command prompt window appears. Type the following commands (marked Step 5: in red) to create two partitions.

  • Page 91: Figure C-5: Partition Creation Commands

    AFL-057A-Z510/Z530 Panel PC system32>format F: /fs:ntfs /q /v:Recovery /y system32>exit Figure C-5: Partition Creation Commands Page 80...

  • Page 92: Install Operating System, Drivers And Applications

    AFL-057A-Z510/Z530 Panel PC NOTE: Use the following commands to check if the partitions were created successfully. Press any key to exit the recovery tool and automatically reboot the system. Step 6: Please continue to the following procedure: Build-up Recovery Partition.S t e p 0 : C.2.3 Install Operating System, Drivers and Applications...

  • Page 93: Build-Up Recovery Partition

    AFL-057A-Z510/Z530 Panel PC C.2.4 Build-up Recovery Partition Put the recover CD in the optical drive. Step 1: Start the system. Step 2: Boot the system from recovery CD. When prompted, press any key to boot Step 3: from the recovery CD. It will take a while to launch the recovery tool. Please be...

  • Page 94: Figure C-8: Build-Up Recovery Partition

    AFL-057A-Z510/Z530 Panel PC The Symantec Ghost window appears and starts configuring the system to Step 5: build-up a recovery partition. In this process, the partition which is created for recovery files in Section C .2.2 is hidden and the recovery tool is saved in this partition.

  • Page 95: Create Factory Default Image

    AFL-057A-Z510/Z530 Panel PC C.2.5 Create Factory Default Image NOTE: Before creating the factory default image, please configure the system to a factory default environment, including driver and application installations. To create a factory default image, please follow the steps below.

  • Page 96: Figure C-12: About Symantec Ghost Window

    AFL-057A-Z510/Z530 Panel PC Figure C-12: About Symantec Ghost Window Use mouse to navigate to the option shown below ( Step 4: F igure C-13). Figure C-13: Symantec Ghost Path Select the local source drive (Drive 1) as shown in F igure C-14. Then click OK.

  • Page 97: Figure C-14: Select A Local Source Drive

    AFL-057A-Z510/Z530 Panel PC Figure C-14: Select a Local Source Drive Select a source partition (Part 1) from basic drive as shown in Step 6: F igure C-15. Then click OK. Figure C-15: Select a Source Partition from Basic Drive Select 1.2: [Recovery] NTFS drive and enter a file name called Step 7: F igure C-16).

  • Page 98: Figure C-16: File Name To Copy Image To

    AFL-057A-Z510/Z530 Panel PC Figure C-16: File Name to Copy Image to When the Compress Image screen in F igure C-17 prompts, click High to make Step 8: the image file smaller. Figure C-17: Compress Image Page 87...

  • Page 99: Figure C-18: Image Creation Confirmation

    AFL-057A-Z510/Z530 Panel PC The Proceed with partition image creation window appears, click Yes to Step 9: continue. Figure C-18: Image Creation Confirmation The Symantec Ghost starts to create the factory default image ( Step 10: F igure C-19). Figure C-19: Image Creation Process...

  • Page 100: Setup Procedure For Linux

    AFL-057A-Z510/Z530 Panel PC The recovery tool main menu window is shown as below. Press any key to Step 12: reboot the system. S t e p 0 : Figure C-21: Press Any Key to Continue C.3 Setup Procedure for Linux The initial setup procedures for a Linux system are mostly the same with the procedure for Microsoft Windows.

  • Page 101: Figure C-22: Partitions For Linux

    AFL-057A-Z510/Z530 Panel PC NOTE: Please reserve enough space for partition 3 for saving recovery images. Figure C-22: Partitions for Linux Create a recovery partition. Insert the recovery CD into the optical disk drive. Step 3: Follow described in Section C .2.2. Then type the following...

  • Page 102: Figure C-23: System Configuration For Linux

    AFL-057A-Z510/Z530 Panel PC recovery partition. After completing the system configuration, press any key to reboot the system. Eject the recovery CD. Figure C-23: System Configuration for Linux Access the recovery tool main menu by modifying the “menu.lst”. To first Step 5: access the recovery tool main menu, the menu.lst must be modified.

  • Page 103: Recovery Tool Functions

    AFL-057A-Z510/Z530 Panel PC The recovery tool menu appears. ( Step 7: F igure C-25) Figure C-25: Recovery Tool Menu Create a factory default image. Follow described in Section Step 8: Step 2 Step 12 C .2.5 to create a factory default image.

  • Page 104: Figure C-26: Recovery Tool Main Menu

    AFL-057A-Z510/Z530 Panel PC Figure C-26: Recovery Tool Main Menu The recovery tool has several functions including: 1. Factory Restore: Restore the factory default image (iei.GHO) created in Section C .2.5. 2. Backup system: Create a system backup image (iei_user.GHO) which will be saved in the hidden partition.

  • Page 105: Factory Restore

    AFL-057A-Z510/Z530 Panel PC C.4.1 Factory Restore To restore the factory default image, please follow the steps below. Type <1> and press <Enter> in the main menu. Step 1: The Symantec Ghost window appears and starts to restore the factory default. A Step 2: factory default image called iei.GHO is created in the hidden Recovery partition.

  • Page 106: Backup System

    AFL-057A-Z510/Z530 Panel PC C.4.2 Backup System To backup the system, please follow the steps below. Type <2> and press <Enter> in the main menu. Step 1: The Symantec Ghost window appears and starts to backup the system. A Step 2: backup image called iei_user.GHO is created in the hidden Recovery partition.

  • Page 107: Restore Your Last Backup

    AFL-057A-Z510/Z530 Panel PC C.4.3 Restore Your Last Backup To restore the last system backup, please follow the steps below. Type <3> and press <Enter> in the main menu. Step 1: The Symantec Ghost window appears and starts to restore the last backup Step 2: image (iei_user.GHO).

  • Page 108: Manual

    AFL-057A-Z510/Z530 Panel PC C.4.4 Manual To restore the last system backup, please follow the steps below. Type <4> and press <Enter> in the main menu. Step 1: The Symantec Ghost window appears. Use the Ghost program to backup or Step 2: recover the system manually.

  • Page 109: Other Information

    AFL-057A-Z510/Z530 Panel PC C.5 Other Information C.5.1 Using AHCI Mode or ALi M5283 / VIA VT6421A Controller When the system uses AHCI mode or some specific SATA controllers such as ALi M5283 or VIA VT6421A, the SATA RAID/AHCI driver must be installed before using one key recovery.
  • Page 110 AFL-057A-Z510/Z530 Panel PC When the following window appears, press <S> to select “Specify Additional Step 5: Device”. In the following window, select a SATA controller mode used in the system. Then Step 6: press <Enter>. The user can now start using the SATA HDD.

  • Page 111: System Memory Requirement

    AFL-057A-Z510/Z530 Panel PC After pressing <Enter>, the system will get into the recovery tool setup menu. Step 7: Continue to follow the setup procedure from in Section Step 4 C .2.2 Create Partitions to finish the whole setup process. S t e p 0 : C.5.2 System Memory Requirement...

  • Page 112: D Terminology

    AFL-057A-Z510/Z530 Panel PC Appendix Terminology Page 101...
  • Page 113 AFL-057A-Z510/Z530 Panel PC Audio Codec 97 (AC’97) refers to a codec standard developed by Intel® AC ’97 in 1997. Advanced Configuration and Power Interface (ACPI) is an OS-directed ACPI configuration, power management, and thermal management interface. Advanced Host Controller Interface (AHCI) is a SATA Host controller AHCI register-level interface.
  • Page 114 AFL-057A-Z510/Z530 Panel PC Direct Memory Access (DMA) enables some peripheral devices to bypass the system processor and communicate directly with the system memory. Dual Inline Memory Modules are a type of RAM that offer a 64-bit data DIMM bus and have separate electrical contacts on each side of the module.
  • Page 115 AFL-057A-Z510/Z530 Panel PC Liquid crystal display (LCD) is a flat, low-power display device that consists of two polarizing plates with a liquid crystal panel in between. Low-voltage differential signaling (LVDS) is a dual-wire, high-speed LVDS differential electrical signaling system commonly used to connect LCD displays to a computer.

  • Page 116: Watchdog Timer

    AFL-057A-Z510/Z530 Panel PC Appendix Watchdog Timer Page 105...
  • Page 117 AFL-057A-Z510/Z530 Panel PC NOTE: The following discussion applies to DOS environment. IEI support is contacted or the IEI website visited for specific drivers for more sophisticated operating systems, e.g., Windows and Linux. The Watchdog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that cause the CPU to crash.
  • Page 118 AFL-057A-Z510/Z530 Panel PC NOTE: When exiting a program it is necessary to disable the Watchdog Timer, otherwise the system resets. EXAMPLE PROGRAM: ; INITIAL TIMER PERIOD COUNTER W_LOOP: AX, 6F02H ;setting the time-out value BL, 30 ;time-out value is 48 seconds ;...
  • Page 119 AFL-057A-Z510/Z530 Panel PC Appendix Hazardous Materials Disclosure Page 108...
  • Page 120 AFL-057A-Z510/Z530 Panel PC F.1 Hazardous Materials Disclosure Table for IPB Products Certified as RoHS Compliant Under 2002/95/EC Without Mercury The details provided in this appendix are to ensure that the product is compliant with the Peoples Republic of China (China) RoHS standards. The table below acknowledges the presences of small quantities of certain materials in the product, and is applicable to China RoHS only.
  • Page 121 AFL-057A-Z510/Z530 Panel PC Part Name Toxic or Hazardous Substances and Elements Lead Mercury Cadmium Hexavalent Polybrominated Polybrominated Biphenyls Diphenyl (Pb) (Hg) (Cd) Chromium (CR(VI)) (PBB) Ethers (PBDE) Housing Display Printed Circuit Board Metal Fasteners Cable Assembly Fan Assembly Power Supply...
  • Page 122 AFL-057A-Z510/Z530 Panel PC 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些元 件将会单独标示出来。 部件名称 有毒有害物质或元素 铅 汞 镉 六价铬 多溴联苯 多溴二苯 醚 (Pb) (Hg) (Cd) (CR(VI)) (PBB) (PBDE) 壳体 显示 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11363-2006 标准规定的限量要求以下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T11363-2006 标准规定的限量要求。...

This manual is also suitable for:

Afl-057a-z530

Table of Contents
