12V SUBMERSIBLE
WATER PUMP
6,750 L/H FLOW
INSTRUCTION MANUAL
SPECIFICATIONS
Voltage:
12V DC
Rated Input Power:84 Watt
Current:
9Amp
Max. Flow Rate: 6,750 litres/hour
Max. Head:
5 meters
ø
Size of Outlet:
29mm
Power Cord:
5m
Weight:
1.4kgs
ozito.com.au
WHAT'S IN THE BOX
12V Submersible Pump
Auxiliary Cable - 2.1m
Cord with On/Off
Switch & 12V DC Plug
SBP- 012
Advertisement
Table of Contents
Related Manuals for Ozito SBP- 012
Summary of Contents for Ozito SBP- 012
- Page 1 12V DC Rated Input Power:84 Watt Current: 9Amp Max. Flow Rate: 6,750 litres/hour Max. Head: 5 meters ø Size of Outlet: 29mm Power Cord: Weight: 1.4kgs ozito.com.au Auxiliary Cable - 2.1m Cord with On/Off Switch & 12V DC Plug SBP- 012...
- Page 2 KNOW YOUR PRODUCT SETUP & PREPARATION SUBMERSIBLE PUMP 1. INSTALLATION GUIDE 1. Pump Housing 4. Discharge Outlet 2. Power Cord 5. Strainer • Pump is suitable for use with fresh and salt water applications. 3. Strainer Tabs • The pump can be used for portable or permanent applications Portable Applications 1.
- Page 3 2. WIRING Wiring Permanent Applications • The submersible pump comes 1. Determine the desired location and position for the pump. Refer supplied with an auxiliary “Portable Applications”. cable. The 12V DC plug on the auxiliary cable enables the pump to be powered from 2.
- Page 4 SUBERSIBLE PUMP FLOAT IN LINE 12V DC SWITCH SWITCH PLUG MOLDED MOLDED CONNECTORS CONNECTORS 3. TROUBLE SHOOTING The two wiring diagrams below show how to set up the submersible Symptom Possible Cure pump without a float switch (manual operation) and with a float Cause switch (automatic operation).
- Page 5 Spare parts can be ordered from the Special Orders Desk at your local Bunnings Warehouse. For further information, or any parts not listed here, visit www.ozito.com.au or contact Ozito Customer Service: Australia 1800 069 486 New Zealand 0508 069 486...
- Page 6 Tool: SPARE PARTS Model No. The following is a list of spare parts carried by Ozito. Please contact Customer Service for any parts not listed. Item Item Description Part No. Description Part No. Strainer SPSBP012-13 Auxiliary Cable SPSBP012-14 How To Order Available spare parts can be ordered through the Special Orders Desk at any Bunnings Warehouse.
- Page 7 GENERAL PUMP SAFETY WARNINGS Read the whole manual carefully and make sure you know how to switch the tool off Avoid accidental starting. Ensure the switch is in the off position before in an emergency, before operating the tool. plugging in. Carrying pumps with your finger on the switch or plugging in pumps that have the switch on invites accidents.
- Page 8 Failure to perform maintenance as set out within the instruction manual. • If the pump is disassembled or tampered with in any way. • Professional, industrial or high frequency use. OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175. 1113...
