SUBMERSIBLE
WATER PUMP
350W
INSTRUCTION MANUAL
SPECIFICATIONS
Motor:
350W
Max. Flow Rate:
7,000l/h
Max. Head
5m
Max. Immersion:
5m
Min. Suction Depth
50mm
Max Particle Size:
Ø30mm
Water Temp.:
1°C - 35°C
Weight:
4.2kg
ozito.com.au
WHAT'S IN THE BOX
Submersible Pump
L-Shape Connector
Universal Adaptor
PSDW-350
Advertisement
Table of Contents
Related Manuals for Ozito PSDW-350
Summary of Contents for Ozito PSDW-350
- Page 1 SUBMERSIBLE WATER PUMP Submersible Pump 350W INSTRUCTION MANUAL SPECIFICATIONS L-Shape Connector Motor: 350W Max. Flow Rate: 7,000l/h Max. Head Max. Immersion: Min. Suction Depth 50mm Max Particle Size: Ø30mm Water Temp.: 1°C - 35°C Weight: 4.2kg ozito.com.au Universal Adaptor PSDW-350...
-
Page 2: Know Your Product
KNOW YOUR PRODUCT SETUP & PREPARATION SUBMERSIBLE PUMP 1. UNIVERSAL ADAPTOR 1. Float Switch Cable 5 Suction Base Ensure the pump is disconnected from the power supply 2. Float Switch Adjustor 6 Outlet before performing any of the following operations. 3. -
Page 3: Operation
OPERATION 2. L-SHAPE CONNECTOR 3. FLOAT SWITCH 1. Screw the L-shape The pump is fitted with a float switch, which controls how connector into the pump the pump switches on and switches off. housing by rotating in a clockwise direction. 1 When the float switch cable is able to move freely the pump will function down to... - Page 4 CAUTION: YOUR PUMP HAS THE CAPACITY TO PUMPING WATER IN A HOME DOMESTIC APPLICATION. DO NOT USE IT FOR CORROSIVE, PUMP WATER WITH A NON SOLID PARTICLE SIZE ABRASIVE, EXPLOSIVE OR DANGEROUS LIQUIDS. OF UP TO 30MM IN DIAMETER. PSDW-350...
-
Page 5: Installation
Pump will not turn off, even The float switch is stuck in the “on” position Ensure that the float switch is free to operate normally. Contact Ozito customer service if the though the water level is low problem still occurs... - Page 6 Replace the extension lead if damaged or defective. Then Note: The supply of 230V and 240V on Ozito pumps are interchangeable for Australia and New Zealand. This using an extension lead on a reel, always unwind the lead completely. Use of an extension lead not suitable for pump is earthed in accordance with AS/NZS 60335-2-41.
- Page 7 BG-DP 3530 Artikel-Nr.: 4170569 Tool: SPARE PARTS Dirt Water Pump Ident-Nr.: 01018 Model No. The following is a list of spare parts carried by Ozito. Please contact Customer Service for any parts not listed. Item Item Description Part No. Description Part No.
-
Page 8: Warranty
• Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175.
