Summary of Contents for Ozito TRP-650
- Page 1 TRANSFER WATER PUMP Transfer Water Pump 600W INSTRUCTION MANUAL SPECIFICATIONS Motor: 600W Max. Flow Rate: 3,600l/h Max. Lift Max. Head: Outlet & Inlet: 25mm (1”)Female Max. Delivery Pressure: 4.0 bar Water Temp.: 1°C - 35°C Hmin=: Weight: 10kg ozito.com.au TRP-650...
-
Page 2: Know Your Product
KNOW YOUR PRODUCT SETUP & PREPARATION TRANSFER PUMP 1. SUCTION INLET 1. Induction Motor 6 Discharge Outlet Ensure the pump is disconnected from the power supply 2. Electrical Box 7 Priming Screw before performing any of the following operations. 3 Adjustable Foot 8 Drain Plug 4 Carry Handle 9 Suction Inlet... - Page 3 2. DISCHARGE OUTLET 3. PRIMING THE PUMP Connecting Hose or Pipe to the Discharge Outlet Priming the pump is required to purge air from the hose Don’t operate the pump without being primed. 1 Ensure the pump’s on/off switch is in the off (0) position and off at 1.
-
Page 4: Operation
NOTE: Ensure the gate valve on your water tank is not left open as this will allow water to drain from the water tank. 3. To turn the pump off, depress the ON/OFF switch to the OFF (0) position. TRP-650... -
Page 5: Installation
Air flow is not allowing the motor to cool Ensure the pump is in a well ventilated area The motor is faulty or damaged l Contact Ozito customer service Poor Performance Faulty suction line Check all the suction lines for leaks or any damage. Replace if they are faulty and check that... - Page 6 Replace the extension lead if damaged or defective. Then Note: The supply of 230V and 240V on Ozito pumps are interchangeable for Australia and New Zealand. This using an extension lead on a reel, always unwind the lead completely. Use of an extension lead not suitable for pump is earthed in accordance with AS/NZS 60335-2-41.
- Page 7 Tool: SPARE PARTS Model No. The following is a list of spare parts carried by Ozito. Please contact Customer Service for any parts not listed. Item Item Description Part No. Description Part No. How To Order Available spare parts can be ordered through the Special Orders Desk at any Bunnings Warehouse. If you have any...
-
Page 8: Warranty
• Failure to perform maintenance as set out within the instruction manual. • If the tool is disassembled or tampered with in any way. OZITO Australia/New Zealand (Head Office) 1-23 Letcon Drive, Bangholme, Victoria, Australia 3175. 1113...
