Aztech WIPC403
Wireless N Pan/Tilt IP Camera

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the wipc403 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aztech wipc403

Summary of Contents for Aztech wipc403

  • Page 1 Aztech WIPC403 Wireless N Pan/Tilt IP Camera...
  • Page 2 AZTECH WIPC403 IP CAMERA USER MANUAL v1.0 © Copyright 2013 All rights reserved. Ver1.0 No part of this document may be reproduced, republished, or retransmitted in any form or by any means whatsoever, whether electronically or mechanically, including, but not limited to, by way of photocopying, recording, information recording, or through retrieval systems without the express written permission.

  • Page 3: Table Of Contents

    AZTECH WIPC403 IP CAMERA USER MANUAL v1.0 Index INTRODUCTION ........................... 5 FUNCTION AND FEATURES ..................... 6 APPEARANCE AND INTERFACE ..................... 7 ..........................7 PPEARANCE ....................... 8 NTERFACE OF QUIPMENT NETWORK CONNECTION ......................8 ...................... 9 ONNECTION NSTRUCTION ........................9 ISIT NSTRUCTION VISIT IP CAMERA FROM LAN ....................
  • Page 4 AZTECH WIPC403 IP CAMERA USER MANUAL v1.0 7.3.3 FTP Service Settings ......................22 7.3.4 Alarm Log Settings ......................23 ..................23 SER AND EVICE ANAGEMENT 7.4.1 Multi-Device Settings ......................23 7.4.2 User Settings ........................24 7.4.3 PTZ Settings ........................24 7.4.4...

  • Page 5: Introduction

    AZTECH WIPC403 IP CAMERA USER MANUAL v1.0 1 Introduction The IP Camera combines a high quality digital video camera with network connectivity and a powerful web server to bring clear video to your mobile phone/desktop from anywhere on your local network or over the Internet.

  • Page 6: Function And Features

    AZTECH WIPC403 IP CAMERA USER MANUAL v1.0 2 Function and Features • Supports Plug and Play Function • VGA/QVGA/QQVGA resolution optional. User can change some specification according to their demands to satisfy his own visual prefer. • Built-in microphone •...

  • Page 7: Appearance And Interface

    AZTECH WIPC403 IP CAMERA USER MANUAL v1.0 3 Appearance and Interface 3.1 Appearance Figure 1 1 – Photovaristor 4 – Internal Mic 2 – Infrared Lights 5 – Heat Dissipation Hole 3 – Lens 6 – Wireless Antenna Remarks: •...

  • Page 8: Interface Of Equipment

    AZTECH WIPC403 IP CAMERA USER MANUAL v1.0 3.2 Interface of Equipment Figure 2 1） Audio Output Socket: Audio output socket is for line-out audio player, such as headphone, speaker, etc. 2） RJ45 Ethernet Socket: RJ45 Ethernet socket is 10/100M self-adjust. The equipment can connect to all kinds of network equipment, such as hub, router, switch, etc.

  • Page 9: Connection Instruction

    The IP addresses of IP Camera and PC should be at the same segment, in Figure 3, the IP Camera-1 can’t be visited. Run the WIPC403 Utility in the CD, click Search button, and then select the IP Camera to reset the IP Camera’s IP address, as the Figure 4.
  • Page 10 WIPC403 IP CAMERA USER MANUAL v1.0 Figure 4 If you have the firewall software in your PC, when you run the WIPC403 Utility, it may pop up a window to say if you want to block this program or not, then you should choose not to block.

  • Page 11: Visit Ip Camera

    AZTECH WIPC403 IP CAMERA USER MANUAL v1.0 open the Browser automatically and pop up a window at the same time which requires to inputting the user name and password. Then you see the home page of the IP Camera-1, just as below Figure 5.

  • Page 12: Menu Column

    AZTECH WIPC403 IP CAMERA USER MANUAL v1.0 Figure 7 5.2.1 Menu Column When you click on the Settings Icon, It will take you to the Settings Page. There are 2 kinds of menu, one is Main Menu, the other is Sub Menu. The Main Menu is highlighted in red background including Device Basic Information, Network Configuration, Alarm Service Settings, User and Device Management;...

  • Page 13: The Control Of Pan/Tilt

    AZTECH WIPC403 IP CAMERA USER MANUAL v1.0 5.2.3 The control of Pan/Tilt At the control area of Pan/Tilt, the user could control the cruise of the Pan/Tilt by the arrowhead direction (Up/Down/Left/Right/Centre/Stop/Left-right cruise/Up-down cruise). When your mouse stops on these control buttons, it will guide you what this button mean.

  • Page 14: Ddns

    AZTECH WIPC403 IP CAMERA USER MANUAL v1.0 example. Figure 9 Select “status” option and remember the WAN IP address, enter the IP address in browser of PC-1, if IP Camra-1 can be visited via PC-1, the port forwarding is successful. And PC-2 and PC-3 can also visit the IP Camera-1.

  • Page 15: Third Party Domain Name

    AZTECH WIPC403 IP CAMERA USER MANUAL v1.0 enter domain name of Figure 10, the browser will connect the device and display the IP address. Figure 10 The domain name is realized by forward manner, the domain name will change into the IP address and port number of the device when visited by domain name.

  • Page 16: Other Settings

    AZTECH WIPC403 IP CAMERA USER MANUAL v1.0 7 Other Settings 7.1 Device Basic Information Page 7.1.1 Device Information Figure 12 This page displays the IP Camera’s Device Firmware Version, System Firmware and WEB UI Firmware Version. 7.1.2 Camera Name Settings Figure 13 This page allows the user to edit the name of the IP Camera.

  • Page 17: Device Date And Time Settings

    AZTECH WIPC403 IP CAMERA USER MANUAL v1.0 7.1.3 Device Date and Time Settings Figure 14 This page allows user to synchronize IP Camera with the current time / PC Time. Select the time zone first. There are three options to set the time and date. One is manually, another is keeping the same as the time and date of the computer, and the third one is getting it from the NTP server.

  • Page 18: Network Configuration Page

    AZTECH WIPC403 IP CAMERA USER MANUAL v1.0 7.2 Network Configuration Page 7.2.1 Basic Network Setting Figure 16 This page allows the user to configure the camera’s IP Address. It may either be DHCP or Static Configuration. Also, user can define the camera’s HTTP Port Number. By default the camera’s port number is 8081.

  • Page 19: Manufacturer's Ddns

    AZTECH WIPC403 IP CAMERA USER MANUAL v1.0 data will fill in the blanks automatically. (For example, SSID, encryption algorithm etc.). User only needs to fill in the password and retype the password. After you configured it, you can click “Apply” button to set it.

  • Page 20: Third Party Ddns

    AZTECH WIPC403 IP CAMERA USER MANUAL v1.0 7.2.4 Third Party DDNS Figure 19 Third Party DDNS: This page allows user to define his own DDNS. User needs to configure Username, Password and Host Information. 7.2.5 UPNP Settings Figure 20 UPNP: UPNP stands for universal plug and play, if you started UPNP, once the IP camera was connected into the LAN, it will communicate with the router of the LAN.

  • Page 21: Alarm Service Settings Page

    AZTECH WIPC403 IP CAMERA USER MANUAL v1.0 7.3 Alarm Service Settings Page 7.3.1 Alarm Service Settings Figure 21 Figure 21 above has listed the motion detect armed input setting. User can set motion detect sensitivity. User can send mail notification, upload image during alarm.

  • Page 22: Mail Service Setting

    AZTECH WIPC403 IP CAMERA USER MANUAL v1.0 7.3.2 Mail Service Setting Figure 22 If user wants to receive email notification during alarms, he must configure this page with the correct data required. The blanks which have been filled with info should be correct. If any info is not filled right, the setting will fail.

  • Page 23: Alarm Log Settings

    AZTECH WIPC403 IP CAMERA USER MANUAL v1.0 Figure 23 7.3.4 Alarm Log Settings Figure 24 This page displays alarm logs that may be useful during debugging purposes. 7.4 User and Device Management 7.4.1 Multi-Device Settings Figure 25...

  • Page 24: User Settings

    AZTECH WIPC403 IP CAMERA USER MANUAL v1.0 User can define up to nine (9) cameras in the Web User Interface. 7.4.2 User Settings Figure 26 There are three levels of authorization; namely Admin/User/Guest. Admin has the highest authority, it can do any change to the settings. User account only can operate the IP camera, can’t do changes to the settings,Guest account can only watch the video, can’t do any...

  • Page 25: Maintain Settings

    AZTECH WIPC403 IP CAMERA USER MANUAL v1.0 7.4.4 Maintain Settings Figure 28 In this page, user can restore the IP Camera in its default settings, power reboot the camera and upgrade its System Firmware and Web UI Firmware. Reboot button to restart the equipment, if you have set the pre-position, and it will turn this position.

  • Page 26: Multi Device Monitor System

    AZTECH WIPC403 IP CAMERA USER MANUAL v1.0 3) Enter the UID. This information is found at the bottom label of the Camera. You may scan the UID’s QR Code or Search the Camera from the Local Area Network. The UID is unique for every device.

  • Page 27: Technical Parameters

    AZTECH WIPC403 IP CAMERA USER MANUAL v1.0 Figure 29 For more information, pls. refer the <<Multi Device Monitor System >> in CD. 9 Technical Parameters Item Sub item Description Sensor 1/4" CMOS sensor Image Total of pixel 300K Capture Minimum illumination IR lights on，0 Lux...
  • Page 28 AZTECH WIPC403 IP CAMERA USER MANUAL v1.0 Operating temperature -10 ~ 50 Humidity 10% ~ 80% non-condensing OS Supported Microsoft Windows 98/2000/XP/Vista etc. Software(PC Internet Explorer6.0 and Above or Browser Side) Compatible Browser, Safari/Firefox etc. Application Software MDMS.exe...
