Unpack the Wine Cellar

WARNING
Excessive Weight Hazard
Use two or more people to move and install wine cellar.
Failure to do so can result in back or other injury.
Remove the Packaging
Remove tape and glue residue from surfaces before turning
on the wine cellar. Rub a small amount of liquid dish soap
over the adhesive with your fingers. Wipe with warm water
and dry.
Do not use sharp instruments, rubbing alcohol, flammable
fluids, or abrasive cleaners to remove tape or glue. These
products can damage the surface of your wine cellar. For
more information, see "Wine Cellar Safety."
Dispose of/recycle all packaging materials.
When Moving Your Wine Cellar:
Your wine cellar is heavy. When moving the wine cellar for
cleaning or service, be sure to protect the floor. Always pull
the wine cellar straight out when moving it. Do not wiggle
or "walk" the wine cellar when trying to move it, as floor
damage could occur.
Clean Before Using
After you remove all of the packaging materials, clean the inside
of your wine cellar before using it. See the cleaning instructions in
"Wine Cellar Care."

Wine Cellar Doors

TOOLS NEEDED: #2 Phillips screwdriver; adjustable wrench
IMPORTANT: All graphics referenced in the following instructions
are included later in this section after "Final Steps." The graphics
shown are for a right-hand swing door (hinges factory installed on
the right).
Remove Door and Hinges
1. Unplug wine cellar or disconnect power.
WARNING
Excessive Weight Hazard
Use two or more people to move and install wine cellar.
Failure to do so can result in back or other injury.
2. Place the wine cellar on its back.
3. Unscrew the two leveling legs, one from the bottom hinge on
the right hand side and one from the left hand side of the
cabinet. See Graphic 4 and 5.
4. Remove the 3 screws from the bottom hinge and remove the
bottom hinge. See graphic 3.
4
NOTE: Keep the hinge in a safe place in the event the wine
cellar door needs to be returned to its original door swing.
5. Remove the door by pulling it downward and off the top pin
and set aside.
6. Remove the 2 plastic screw caps located on the top of the
hinge cover. See Graphic 2.
7. Remove the screws holding the hinge cover to the top hinge
and remove the top hinge cover. See Graphic 2.
8. Remove the 3 screws from the top hinge and remove the top
hinge. See Graphic 2.
Reverse Door Swing (optional)
1. Remove the plastic door pin cap from the top left side of the
door and reinstall it on the right side of the door.
2. Remove the 3 plastic screw caps from the top left side of the
cabinet and transfer them to the top right side of the cabinet.
See Graphic 1.
3. Install the top hinge on the left side of the cabinet and secure
with the 3 screws.
4. Install the hinge cover over the top hinge using the 2 screws.
5. Install the 2 plastic screw caps on the hinge cover.
6. Insert the top corner of the door into the top hinge pin and
reinstall the door on the wine cellar.
7. Using the left side bottom hinge supplied with your wine
cellar, insert the hinge pin into the bottom of the door. See
Graphic 6.
8. Align the hinge holes with the holes in the cabinet and secure
with 3 screws.
9. Install the leveling leg that was in the right bottom hinge into
the left bottom hinge. See Graphic 4.
10. Install the leveling leg that was on the left side of the wine
cellar onto the right side. See Graphic 5.
Final Steps
1. Check the alignment of the door and the door seals.
2. Check to see that the door lock slides easily into the lock
chamber.
3. Tighten all hinge screws.
4. Return the wine cellar to its upright position and wait
60 minutes before reconnecting the power.
WARNING
Electrical Shock Hazard
Plug into a grounded 3 prong outlet.
Do not remove ground prong.
Do not use an adapter.
Do not use an extension cord.
Failure to follow these instructions can result in death,
fire, or electrical shock.
5. Plug in wine cellar or reconnect power.
