SPECIFICATIONS AND FEATURES

Operating Frequencies (MHz):
Block 21 537.600 - 563.100
Block 22 563.200 - 588.700
Block 23 588.800 - 614.300
Block 24 614.400 - 639.900
Block 25 640.000 - 665.500
Block 26 665.600 - 691.100
Block 27 691.200 - 716.700
Frequency Adjustment Range:
Receiver Type:
Frequency Stability:
Front end bandwidth:
Sensitivity
20 dB Sinad:
60 dB Quieting:
Squelch quieting:
AM rejection:
Modulation acceptance:
Image and spurious rejection:
Third order intercept:
Diversity method:
FM Detector:
Antenna inputs:
Audio outputs
Rear Panel XLR:
Front Panel Controls and Indicators:
Main control panel
Frequency screen
Level
Battery levels
Scanning mode
Test tone
Rear Panel Controls and features:
Power Options:
Ext DC:
z Int Batt:
Battery Life:
9V alkaline
9V lithium
Weight:
Dimensions:
Block 28 716.800 - 742.300
Block 29 742.400 - 767.900
Block 30 768.000 - 793.500 (outside USA)
Block 31 793.600 - 819.100 (outside USA)
Block 32 819.200 - 844.700 (outside USA)
Block 33 844.800 - 865.000 (outside USA)
25.5 MHz in 100kHz steps
Triple conversion, superheterodyne, 244MHz , 10.7MHz and 300kHz
±0.001 %
+/- 30MHz @ -3dB
0.9 uV (-108 dBm), A weighted
1.12 uV (-106 dBm), A weighted
Greater than 125 dB*
Greater than 60 dB, 2 uV to 1 Volt (Undetectable after processing)
>90 kHz
>85dB
0 dBm
Phased antenna diversity
Digital Pulse Counting Detector operating at 300kHz
Dual fixed - made of marine phosphor bronze
Calibrated into an actual output impedance, approx 500 Ohms.
Typical 10K Ohm balanced load, adjustable
from -50dBu to +10dBu in 1dB steps
LCD control panel - menus include:
Pilot tone; antenna phase, receiver battery level;
transmitter battery level; audio level, RF level
Frequency, TV channel; Transmitter switch setting
Audio output level from -50Bu to +10dBu
Both transmitter and receiver in 1/10th volt steps.
Coarse and fine screens for spectrum check
1kHz, -50dBm to +10dBm output, < 5% THD
XLR audio output jack; External DC input; Battery compartment access
Minimum 10 Volts to maximum 18 Volts DC; 1.6 W, 100 mA at 12VDC
9V alkaline or lithium (90 mA @ 9V, 120mA @ 6V)
3.5 hours continuous, 4 hours intermittent
Up to 12 hours (continuous and intermittent usage are the same)
10.7oz.
2.83" wide x 1.25" high x 4.64" deep
Specifications subject to change without notice.
Rio Rancho, NM – USA
UHF Wireless Diversity Receiver
