- Page 1 ® SPLIT LID TABLE TOP TWO SIDED TOASTER MODEL CG14SPTS-120V CG14SPTS-120C Installation and Operation Instructions 2M-Z5634 Rev. C 11/18/09...
-
Page 2: Safety Symbol
SAFETY SYMBOL These symbols are intended to alert the user to the presence of important operating and maintenance instructions in the manual accompanying the appliance. RETAIN THIS MANUAL FOR FUTURE REFERENCE NOTICE Using any part other than genuine Star factory supplied parts relieves the manufacturer of all liability. -
Page 3: General Installation Data
GENERAL INSTALLATION DATA CAUTION This equipment is designed and sold for commercial use only by personnel trained and experienced in its operation and is not sold for consumer use in and around the home nor for use directly by the general public in food service locations. The unit time and temperature are preset by the factory to the customer requirements. - Page 4 TEMPERATURE/TIMER CONTROLLER OPERATION SPECIFICATIONS Start-up: 1. The preset time display will flash until preset temperature is reached. 2. When the control reaches preset temperature, time display, "Heat On" indicator and "START/STOP" indicator will stop flashing and the alarm will beep three times. Temperature: 1. To view the actual temperature, press and hold "Temp Button". Display will read "Lo F" if temperature is below 273°F and "Hi F" if temperature is above 573°F. To Program Time and Temperature: Note: While programming, if no input is received for approximately 15 seconds, the unit will exit programming mode and revert to operational mode. 1. Press and hold "Temp" (actual temperature displays).
-
Page 5: Daily Cleaning Procedures
Right Side (Timer only): 1. To change the time on the right side, press and hold the "TEMP" button and the "START/ STOP" button on the right side for 3 seconds. The display above the "START/STOP" button will change from the time to "_ _ _ _." Release the "TEMP" and "START/STOP" buttons. - Page 6 CAUTION DO NOT SPLASH CONTROL HOUSING! Do not splash conduit connecting top and bottom of the toaster! MAINTENANCE AND REPAIRS Contact your local authorized service agent for service or required maintenance. Refer to the authorized service center listing provided with the unit. STAR Service Help Desk: 314-678-6303 Please have your serial number and model number for faster service.
- Page 7 Visit our Website at: www.star-mfg.com Email: service@star-mfg.com THOROUGHLY INSPECT YOUR UNIT ON ARRIVAL This unit has been tested for proper operation before leaving our plant to insure delivery of your unit in perfect condition. However, there are instances in which the unit may be damaged in transit. In the event you discover any type of damage to your product upon receipt, you must immediately contact the transportation company who delivered the item to you and initiate your claim with same.
- Page 10 28.1 B Style Hinge Counterbalance NAMEPLATE GR14SPTIP240 4“ LEGS ONLY SOME ITEMS ARE INCLUDED FOR ILLUSTRATIVE PURPOSES ONLY AND IN CERTAIN INSTANCES MAY NOT BE AVAILABLE This drawing contains information confidential = B Style Hinge Units Only to Star Manufacturing International, Inc. No reproduction or disclosure of its contents is permitted.
-
Page 11: Parts List
PARTS LIST January 16, 2013, Rev. C CG14SPTS-120V SPLIT LID TABLE TOP CLAM SHELL TOASTER MODEL Number Part Description Unit Number Number 2M-Z2620 LABEL CAUTION, BI-LINGUAL 2C-Z3200 PIN - TOP HOUSING 2A-Z3827 PLATE, STAMPING CONDUIT D9-GR0181 TOP HOUSING & CONDUIT AY. 2C-Z5883 10-24 X 1/2"FZA SCREW, TOP HOUSING B9-04-WB-0046 CLAMP WIRE SUPPORT D9-GR0182 TOP RETAINING PLATE ASSEMBLY D9-Z2133 INSULATION FIBERGLAS TOP 2A-Z6604 SPACER, INSULATION PLATE D9-Z3902 PLATE - TOP ELEMENT RET. - Page 12 PARTS LIST January 16, 2013, Rev. C CG14SPTS-120V SPLIT LID TABLE TOP CLAM SHELL TOASTER MODEL Number Part Description Unit Number Number 2E-Z4119 CORD POWER D9-GR0193 CORD POWER 9D-CG14SPTS-120C D9-GR0189 TOP BURN GUARD AY. D9-GR0177 BURN GUARD ASSEMBLY - LEFT D9-GR0176 BURN GUARD ASSEMBLY - RIGHT PS-GR0362 KIT, 2F-Z1947 CASTING, GROOVED BOTTOM, ALUMINUM 2N-Z9324 ELEMENT, HEATING, 1300 W 2C-08-07-0285 SCREW 10-24 X 3/4 X 3/8 D9-Z2618 BTM ELEMENT RET. PLATE D9-Z2888 INSULATION - 14"...
