- Page 1 ® SPLIT LID TABLE TOP TWO SIDED TOASTER MODEL GR14SPT-240V Installation and Operation Instructions 2M-Z4319 Rev. C 9/29/06 GR14SPT...
-
Page 2: Safety Symbol
SAFETY SYMBOL These symbols are intended to alert the user to the presence of important operating and maintenance instructions in the manual accompanying the appliance. RETAIN THIS MANUAL FOR FUTURE REFERENCE NOTICE Using any part other than genuine Star factory supplied parts relieves the manufacturer of all liability. -
Page 3: Installation
GENERAL INSTALLATION DATA CAUTION This equipment is designed and sold for commercial use only by personnel trained and experienced in its operation and is not sold for consumer use in and around the home nor for use directly by the general public in food service locations. INSTALLATION 1. - Page 4 TEMPERATURE/TIMER CONTROLLER OPERATION SPECIFICATIONS Startup: 1. The preset time will fl ash until preset temperature is reached. 2. When the control reaches preset temperature, time display, "Heat On" indicator and program indicator will stop fl ashing and the alarm will beep three times. Temperature: 1.
-
Page 5: Monthly Inspection
MONTHLY INSPECTION Check all bolts/screws and tighten if necessary. CLEANING All surfaces except the cooking grids are stainless steel and can be cleaned with a warm, damp cloth and detergent. CAUTION DO NOT IMMERSE OR LET THE UNIT STAND IN WATER. DO NOT HOSE DOWN. - Page 6 Visit our Website at: www.star-mfg.com Email: service@star-mfg.com THOROUGHLY INSPECT YOUR UNIT ON ARRIVAL This unit has been tested for proper operation before leaving our plant to insure delivery of your unit in perfect condition. However, there are instances in which the unit may be damaged in transit. In the event you discover any type of damage to your product upon receipt, you must immediately contact the transportation company who delivered the item to you and initiate your claim with same.
- Page 7 MATERIAL MODEL NO. PART NO. ---------- SK1857 SK1857 GR14SPT-240V GR14SPT-240V STAR MFG. INTERNATIONAL, INC. STAR MFG. INTERNATIONAL, INC. #10 SUNNEN DRIVE, ST. LOUIS, MO. 63143, USA #10 SUNNEN DRIVE, ST. LOUIS, MO. 63143, USA FINISH TITLE WIRE DIAGRAM, 240V, 2300 WATT...
- Page 8 Nameplate SOME ITEMS ARE INCLUDED FOR ILLUSTRATIVE PURPOSES ONLY AND IN CERTAIN INSTANCES MAY NOT BE AVAILABLE STAR MANUFACTURING INTERNATIONAL, INC MODEL - GR14SPT SK1750 REV. E 3/22/06...
-
Page 9: Parts List
PARTS LIST September 28, 2006, Rev. C GR14SPT-240V SPLIT LID TABLE TOP MODEL CLAM SHELL TOASTER Number Part Number Description Number Unit D9-GR0032 TORQUE BOX ASSEMBLY D9-GR0150 GREASE CABINET ASSEMBLY D9-GR0152 BODY ASSEMBLY D9-GR0177 BURN GUARD ASSEMBLY - LEFT D9-GR0176... - Page 10 PARTS LIST September 28, 2006, Rev. C 9D-GR14SPT-240V SPLIT LID TABLE TOP CLAM SHELL TOASTER MODEL Number Part Number Number Description Unit D9-GR0189 TOP BURN GUARD AY. D9-GR0183 INSULATION BAFFLE AY. D9-Z3826 INSULATION - BAFFLE IMPORTANT: WHEN ORDERING, SPECIFY VOLTAGE OR TYPE GAS DESIRED...
- Page 12 STAR MANUFACTURING 10 Sunnen Drive, St. Louis, MO 63143 U.S.A. (800) 807-9054 (314) 781-2777 Parts & Service (800) 807-9054 www.star-mfg.com...
