- Page 1 ® TABLE TOP TWO SIDED TOASTER MODEL 9D-GR10T4K-UK Installation and Operation Instructions 2M-Z9364 Rev. - 1/24/2006...
-
Page 2: Safety Symbol
SAFETY SYMBOL These symbols are intended to alert the user to the presence of important operating and maintenance instructions in the manual accompanying the appliance. RETAIN THIS MANUAL FOR FUTURE REFERENCE NOTICE Using any part other than genuine Star factory supplied parts relieves the manufacturer of all liability. -
Page 3: Electrical Specifications
ELECTRICAL SPECIFICATIONS Model No. Volts Rated Wattage Amps Power Inlet GR10T4K-UK 1653 IEC320 C20 Power inlet GENERAL INSTALLATION DATA CAUTION This equipment is designed and sold for commercial use only by personnel trained and experienced in its operation and is not sold for consumer use in and around the home nor for use directly by the general public in food service locations. -
Page 4: Setting The Temperature
SEASONING THE COOKING SURFACES FIRST TIME SEASONING Follow your company/corporate guidlines for seasoning cooking surfaces. or 1. Bring the grill to 300°F and leave it on while doing the next three steps. 2. Brush the cooking surfaces with a release agent. If using an aerosol agent, fi... -
Page 5: On/Off Toggle Switch
ON/OFF TOGGLE SWITCH The switch turns the unit on and off. The switch has three positions: With the switch in this position, both top and bottom platens will heat. With the switch in this position, neither platen will heat; the unit is OFF. With the switch in this position only the bottom platen will heat. - Page 6 CLEANING Begin cleaning procedure by using the operating procedures within your organization, or follow the steps below: 1. If particles adhere to the cooking surface during the day, scrape them off with a spatula. NOTE: It is best not to let food cook onto the grill, as food build-up on the grill will increase sticking and smoking.
-
Page 7: Operation Troubleshooting
OPERATION TROUBLESHOOTING A. Unit is not heating. 1. Check if the unit is plugged into the correct receptacle. 2. Check the incoming power line. 3. Check that the switch is in the correct position. 4. Check that the thermostat is set to the proper temperature. B. -
Page 8: Parts Warranty
INTERNATIONAL ONE (1) YEAR EQUIPMENT WARRANTY All workmanship and materials in “STAR” products are warranted for a period of one year from the date shipped from the factory or one year from the date shown on the proof of purchase of the end-user when purchased through an authorized “STAR” dealer/dis- tributor in a commercial foodservice location. - Page 9 UNITS WITH IEC CONNECTOR: POWER INLET CONNECTOR: IEC 320 C-20 POWER INLET, ON ALL 208 - 240V UNITS. FOR USE WITH DETACHABLE CORDSETS SUPPLIED WITH A STRAIGHT, FEMALE, IEC 60320 C-19 CONNECTOR. REAR OF CONNECTOR SHOWN. NORTH AMERICA: TOP ELEMENT 15 AMP PLUG NEMA 5-15P ON 120V, 1,800 WATT UNITS FOR U.S.
- Page 10 NAMEPLATE This drawing contains information confidential to Star Manufacturing International, Inc. No reproduction or disclosure of its contents is permitted. SOME ITEMS ARE INCLUDED FOR STAR MANUFACTURING INTERNATIONAL, INC. ILLUSTRATIVE PURPOSES ONLY AND IN CERTAIN INSTANCES MAY NOT BE AVAILABLE 1/10/2006 MODEL: GR10T4K SK2164...
-
Page 11: Parts List
PARTS LIST January 24, 2006 Rev. - Star Two-Sided Grill GR10T4K-UK MODEL Number Part Number Number Description Unit 2M-Z9363 OVERLAY W/TIMER - 10" 2J-Z7668 TIMER CONTROL 2K-Z1971 SPACER 2E-Z6863 SWITCH - 3 POSITION 2R-Z4621 KNOB - CONTROL 2T-6447 THERMOSTAT 118V-236V D9-GR0234 FACEPLATE ASSEMBLY - 10"...
